UPS nJoy Balder 2000 Putere 2000 VA / 2000 W Tip On-line Tensiune nominala la intrare 230 VAC Plaja acceptata tensiune intrare 110-300 VAC ± 5% la 50% sarcina 160-300 VAC ± 5% la 100% sarcina Tensiune nominala la iesire 200*/208*/220/230/240 VAC *Capacitatea scade la 80% cand este ajustata tensiunea la 200 / 208 VAC Frecventa 40Hz ~ 70 Hz Eficienta Eficienta pana la 96% Conectori Intrare: 1 x IEC-320 C14 Iesire: 8 x IEC-320 C13 Timpul de transfer baterie / AC AC-DC: ZERO Invertor la bypass: 4ms Timp mediu de functionare pe baterii 25% incarcare – 32 min 50% incarcare – 13 min 75% incarcare – 8 min 100% incarcare – 4 min Porturi comunicare RS232 / USB / Intelligent Port (nu e inclus in pachet) Tipul bateriei Sigilata si protejata impotriva scurgerilor Specificatii baterie 6x CSB GP 1272 Software ViewPower Pro: https://www.power-software-download.com/viewpowerpro.html Caracteristici Dubla conversie Factor de putere la iesire 1.0 Eficienta de pana la 94% Functia Eco Cabinet de baterii extern (optional) Software management Ecran LCD usor de folosit Design rack/tower Afisaj LCD Mod AC, mod baterie, nivel incarcare, nivel baterie, tensiunea de intrare, tensiunea de iesire, suprasarcina, eroare, baterie descarcata Mediu de functionare Umiditate: 0-90 % (fara condensare) Temperatura: 0-40 grade Celsius Zgomot mai redus de 50 dB Dimensiuni fizice Dimensiuni: 630 x 438 x 88 mm Greutate: 23.3 kg https://www.njoy.ro/ro/ups-commercial/balder-2000#specificatii
USB-Port | |
---|---|
Capacitate putere UPS | |
Product colour | Black |
Master (outer) case height | 200 mm |
LED indicators | Yes |
Operating temperature (T-T) | 0 – 40 °C |
Height | 88 mm |
Battery recharge time | 3 h |
Products per master (outer) case | 1 pc(s) |
Response time | 4 ms |
RS-232 ports | 1 |
Display type | LCD |
Operating relative humidity (H-H) | 0 – 95% |
Control type | Buttons |
Certification | CE, RoHS |
Surge protection | Yes |
Tip UPS | |
Capacitate Rack | 2U |
Ecran LCD | |
Port USB | Da |
Number of input phases | 1 |
AC outlet types | C13 coupler |
Input operation voltage (max) | 300 V |
Hot-swap battery | Yes |
Cold start | Yes |
Output operation voltage (max) | 240 V |
Emergency Power Off (EPO) | Yes |
Power plug | C20 coupler |
AC outlets quantity | 8 AC outlet(s) |
Form factor | |
Rack capacity | 2U |
Auto-restart | Yes |
UPS topology | Double-conversion (Online) |
Crest factor | 3:1 |
Waveform | Pure sine |
Number of batteries supported | 6 |
Output operation voltage (min) | 200 V |
Noise level | 50 dB |
Input operation voltage (min) | 110 V |
Output frequency | 47/53 Hz |
Surge energy rating | 624 J |
Power factor | 0.99 |
Output voltage Total Harmonic Distortion (THD) | 4% |
Input current Total Harmonic Distortion (THD) | 5% |
Power protection features | Overcharge, Overdischarge, Overheating, Overload |
Modem (RJ-11) ports | 2 |
Typical backup time at full load | 4 min |
Typical backup time at half load | 13 min |
Width | 438 mm |
Output power capacity | 2 kVA |
Output power | 2000 W |
Master (outer) case width | 565 mm |
Master (outer) case length | 700 mm |
Depth | 630 mm |
Weight | 23.3 kg |
Master (outer) case net weight | 23.3 kg |
Master (outer) case gross weight | 25.5 kg |
