Sursa ASUS ROG LOKI SFX-L, 80+ Platinum, RGB, 750W

Surse PC

Sursa ASUS ROG LOKI SFX-L, 80+ Platinum, RGB, 750W

(0) Stoc epuizat
Vândut de RITC.ro Cod produs: ROG LOKI 750P

Livrare și beneficii

Livrare rapidă 24–48 ore prin curier Livrare rapidă Retur gratuit în 30 de zile Retur 30 de Garanție inclusă 24 luni garanție oficială Garanție 24 luni

Compară cu produse similare

Vezi comparația completă
Caracteristică Sursa ASUS ROG LOKI SFX-L, 80+ Platinum, RGB, 750W Sursa GENESIS Nihon 750NM, 80+ Bronze, 750W Sursa GENESIS Nihon 750NM, 80+ Bronze, 750W Sursa MSI PRO A850PL PCIE5, 80 PLUS Platinum, 850 W Sursa GENESIS Nihon 650NM, 80+ Bronze, 650W
Alte caracteristici
80 PLUS certification 80 PLUS Platinum 80 PLUS Bronze 80 PLUS Bronze 80 PLUS Platinum 80 PLUS Bronze
ATX version — 3.1 3.1 — 3.1
Bearing technology — FDB FDB — FDB
Cables included — AC AC — AC
Cabling type Fully-Modular Non-Modular Non-Modular Fully-Modular Non-Modular
Certificare 80 Plus 80 PLUS Platinum 80 PLUS Bronze 80 PLUS Bronze 80 PLUS Platinum 80 PLUS Bronze
Combined power (+3.3V) 110 W 100 W 100 W 100 W 100 W
Combined power (+5V) 110 W 100 W 100 W 100 W 100 W
Combined power (+5Vsb) 12.5 W 15 W 15 W 12.5 W 15 W
Combined power (-12V) 9.6 W 750 W 750 W 849.6 W 3.6 W
Compliance certificates — CE, RoHS, UKCA CE, RoHS, UKCA — CE, RoHS, UKCA
Cooling type — Active Active Active Active
Country of origin — China China — China
CPU power cable length — 85 cm 85 cm — 85 cm
CPU power connector (4+4 pin) Yes Yes Yes Yes Yes
Cybenetics certification — Silver Silver — Silver
Cybenetics noise rating — Standard++ Standard++ — Standard++
Efficiency — 88% 88% 80Plus-Platinum 88%
Fan diameter 12 cm 12 cm 12 cm 12 cm 12 cm
Illumination Yes No No — No
Iluminare RGB Da Nu Nu Nu Nu
Input current — 9 - 4.5 A 9 - 4.5 A — 8 - 4 A
Max output current (+3.3V) 20 A 20 A 20 A 20 A 20 A
Max output current (+5V) 20 A 20 A 20 A 20 A 20 A
Max output current (+5Vsb) 2.5 A 3 A 3 A 2.5 A 3 A
Max output current (-12V) 0.8 A 62.5 A 62.5 A 70.8 A 0.3 A
Mean time between failures (MTBF) — 80000 h 80000 h — 80000 h
Motherboard power cable length — 55 cm 55 cm 60 cm 55 cm
Motherboard power connector 20+4 pin ATX 20+4 pin ATX 20+4 pin ATX 20+4 pin ATX 20+4 pin ATX
Noise level — 24.7 dB 24.7 dB — 24.7 dB
Number of EPS connectors — 2 2 — 2
Number of fans 1 fan(s) 1 fan(s) 1 fan(s) 1 fan(s) 1 fan(s)
Number of SATA power cables — 2 2 — 2
Number of SATA power connectors 6 6 6 6 6
On/off switch — Yes Yes Yes Yes
Operating temperature (T-T) — 0 - 40 °C 0 - 40 °C — 0 - 40 °C
Package depth 190 mm 290 mm 290 mm — 290 mm
Package height 100 mm 125 mm 125 mm — 125 mm
Package weight 2.5 kg 2.52 kg 2.52 kg — 2.36 kg
Package width 285 mm 240 mm 240 mm — 240 mm
Packaging content — User guide, Set of assembly elements, Velcro bands, Cable combs User guide, Set of assembly elements, Velcro bands, Cable combs — User guide, Set of assembly elements, Velcro bands, Cable combs
PCI Express connector — Yes Yes — Yes
PCI Express power cable length — 67 cm 67 cm — 67 cm
PCI Express power connectors (16-pin) 3 3 3 3 3
Peripheral (Molex) power cable length — 750 mm 750 mm — 750 mm
Peripheral (Molex) power connectors (4-pin) 4 2 2 2 2
PFC Active — — Active —
Power Factor Correction (PFC) type — Active Active Active Active
Power supply unit (PSU) form factor SFX ATX ATX ATX ATX
PSU Power 750 W 750 W 750 W 850 W 650 W
PSU Type SFX-L ATX ATX ATX ATX
Purpose PC PC PC PC PC
SATA power cable length — 450,550,650 mm 450,550,650 mm — 450,550,650 mm
TOTAL-POWER 750 W 750 W 750 W 850 W 650 W
Caracteristici fizice
Greutate 1.81 kg 2.13 kg 2.13 kg — 1.96 kg
Laptopuri - Caracteristici fizice 25.09
Adâncime 125 mm 140 mm 140 mm 150 mm 140 mm
Lățime 125 mm 150 mm 150 mm 150 mm 150 mm
Înălțime 63.5 mm 86 mm 86 mm 86 mm 86 mm
Laptopuri - Conectivitate și porturi 25.09
Conectivitate wireless Full - Modular Non Modular Non Modular Full - Modular Non Modular
Laptopuri - Construcție
Culoare Black, Silver Black Black Black Black
Laptopuri - Generale
Garanție comercială 120 — — — 12
Producător ASUS GENESIS GENESIS MSI GENESIS

Analiză inteligentă a produsului

În curând vei putea afla mai multe informații despre produs, generate cu inteligență artificială.

Descriere oficială

Sursa ASUS ROG LOKI 750W 80+Platinum Intel Form Factor SFX-L ATX 3.0 Yes Dimensions 125 x 125 x 63.5 mm Efficiency 80Plus Platinum Protection Features OPP/OVP/UVP/SCP/OCP/OTP Hazardous Materials ROHS AC Input Range 100-240Vac DC Output Voltage +3.3V +5V +12V -12V +5Vsb Maximum Load 20A 20A 62.5A 0.8A 2.5A Combined Load 110W 110W 750W 9.6W 12.5W Total Output 750W Connectors MB 24/20-pin x 1 CPU 4+4-pin x 2 PCI-E 16-pin x 1 PCI-E 8-pin x 3 SATA x 6 PERIPHERAL x 4

Specificații tehnice 41 caracteristici
80 PLUS certification
80 PLUS Platinum
Cabling type
Fully-Modular
Certificare 80 Plus
80 PLUS Platinum
Certification
OPP/OVP/UVP/SCP/OCP/OTP
Combined power (+3.3V)
110 W
Combined power (+5V)
110 W
Combined power (+5Vsb)
12.5 W
Combined power (-12V)
9.6 W
CPU power connector (4+4 pin)
Yes
Fan diameter
12 cm
Illumination
Yes
Iluminare RGB
Da
Max output current (+3.3V)
20 A
Max output current (+5V)
20 A
Max output current (+5Vsb)
2.5 A
Max output current (-12V)
0.8 A
Motherboard power connector
20+4 pin ATX
Number of fans
1 fan(s)
Number of SATA power connectors
6
Package depth
190 mm
Package height
100 mm
Package weight
2.5 kg
Package width
285 mm
PCI Express power connectors (16-pin)
3
Peripheral (Molex) power connectors (4-pin)
4
PFC
Active
Power supply unit (PSU) form factor
SFX
PSU Power
750 W
PSU Type
SFX-L
Purpose
PC
Silent mode
Yes
Supported motherboard form factors
ATX
TOTAL-POWER
750 W
Greutate
1.81 kg
Adâncime
125 mm
Lățime
125 mm
Înălțime
63.5 mm
Conectivitate wireless
Full - Modular
Culoare
Black, Silver
Garanție comercială
120
Producător
ASUS
