Sursa DEEPCOOL PL550D V2, 80 PLUS Bronze, 550 W

Surse PC

Sursa DEEPCOOL PL550D V2, 80 PLUS Bronze, 550 W

(0) Stoc epuizat
Vândut de RITC.ro Cod produs: R-PL550D-FC0B-EU V2

Livrare și beneficii

Livrare rapidă 24–48 ore prin curier Livrare rapidă Retur gratuit în 30 de zile Retur 30 de Garanție inclusă 24 luni garanție oficială Garanție 24 luni

Compară cu produse similare

Vezi comparația completă
Caracteristică Sursa DEEPCOOL PL550D V2, 80 PLUS Bronze, 550 W Sursa GENESIS Nihon 650NM, 80+ Bronze, 650W Sursa GENESIS Nihon 750NM, 80+ Bronze, 750W Sursa GENESIS Nihon 750NM, 80+ Bronze, 750W Sursa MSI MAG A750BN PCIE5 II, 80+ Bronze, 750W
Alte caracteristici
80 PLUS certification 80 PLUS Bronze 80 PLUS Bronze 80 PLUS Bronze 80 PLUS Bronze 80 PLUS Bronze
ATX version 3.1 3.1 3.1 3.1 —
Bearing technology HYB FDB FDB FDB —
Cables included — AC AC AC —
Cabling type Non-Modular Non-Modular Non-Modular Non-Modular Non-Modular
Certificare 80 Plus 80 PLUS Bronze 80 PLUS Bronze 80 PLUS Bronze 80 PLUS Bronze 80 PLUS Bronze
Combined power (+3.3V) 100 W 100 W 100 W 100 W 120 W
Combined power (+5V) 100 W 100 W 100 W 100 W 120 W
Combined power (+5Vsb) 15 W 15 W 15 W 15 W 15 W
Combined power (-12V) 3.6 W 3.6 W 750 W 750 W 750 W
Compliance certificates RoHS, WEEE CE, RoHS, UKCA CE, RoHS, UKCA CE, RoHS, UKCA —
Cooling type Active Active Active Active Active
Country of origin China China China China —
CPU power cable length — 85 cm 85 cm 85 cm —
CPU power connector (4+4 pin) Yes Yes Yes Yes —
Cybenetics certification — Silver Silver Silver —
Cybenetics noise rating — Standard++ Standard++ Standard++ —
Efficiency 80Plus-Bronze 88% 88% 88% 85%
Fan diameter 12 cm 12 cm 12 cm 12 cm 12 cm
Illumination — No No No No
Iluminare RGB Nu Nu Nu Nu Nu
Input current 8 - 4 A 8 - 4 A 9 - 4.5 A 9 - 4.5 A —
Max output current (+3.3V) 20 A 20 A 20 A 20 A 20 A
Max output current (+5V) 20 A 20 A 20 A 20 A 20 A
Max output current (+5Vsb) 3 A 3 A 3 A 3 A 32.5 A
Max output current (-12V) 0.3 A 0.3 A 62.5 A 62.5 A 62.5 A
Mean time between failures (MTBF) 100000 h 80000 h 80000 h 80000 h —
Motherboard power cable length 55 cm 55 cm 55 cm 55 cm —
Motherboard power connector 20+4 pin ATX 20+4 pin ATX 20+4 pin ATX 20+4 pin ATX 24-pin ATX
Noise level — 24.7 dB 24.7 dB 24.7 dB —
Number of EPS connectors — 2 2 2 —
Number of fans 1 fan(s) 1 fan(s) 1 fan(s) 1 fan(s) 1 fan(s)
Number of SATA power cables — 2 2 2 —
Number of SATA power connectors 6 6 6 6 1
On/off switch Yes Yes Yes Yes Yes
Operating temperature (T-T) 0 - 40 °C 0 - 40 °C 0 - 40 °C 0 - 40 °C —
Package depth — 290 mm 290 mm 290 mm —
Package height — 125 mm 125 mm 125 mm —
Package weight — 2.36 kg 2.52 kg 2.52 kg —
Package width — 240 mm 240 mm 240 mm —
Packaging content — User guide, Set of assembly elements, Velcro bands, Cable combs User guide, Set of assembly elements, Velcro bands, Cable combs User guide, Set of assembly elements, Velcro bands, Cable combs —
PCI Express connector — Yes Yes Yes —
PCI Express power cable length — 67 cm 67 cm 67 cm —
PCI Express power connectors (16-pin) 1 3 3 3 2
Peripheral (Molex) power cable length — 750 mm 750 mm 750 mm —
Peripheral (Molex) power connectors (4-pin) 2 2 2 2 1
Power Factor Correction (PFC) type Active Active Active Active Active
Power supply unit (PSU) form factor ATX ATX ATX ATX ATX
PSU Power 550 W 650 W 750 W 750 W 750 W
PSU Type ATX ATX ATX ATX ATX
Purpose PC PC PC PC PC
SATA power cable length 450,550,650 mm 450,550,650 mm 450,550,650 mm 450,550,650 mm —
TOTAL-POWER 550 W 650 W 750 W 750 W 750 W
Caracteristici fizice
Greutate — 1.96 kg 2.13 kg 2.13 kg —
Laptopuri - Caracteristici fizice 25.09
Adâncime 140 mm 140 mm 140 mm 140 mm 140 mm
Lățime 150 mm 150 mm 150 mm 150 mm 150 mm
Înălțime 86 mm 86 mm 86 mm 86 mm 86 mm
Laptopuri - Conectivitate și porturi 25.09
Conectivitate wireless Non Modular Non Modular Non Modular Non Modular Non Modular
Laptopuri - Construcție
Culoare Black Black Black Black Black
Laptopuri - Generale
Garanție comercială 60 12 — — —
Producător DEEPCOOL GENESIS GENESIS GENESIS MSI

Analiză inteligentă a produsului

În curând vei putea afla mai multe informații despre produs, generate cu inteligență artificială.

Descriere oficială

Sursa DEEPCOOL PL550D V2 550W 80 PLUS Bronze, Active PFC+DC to DC, Eficienta 85% sub incarcare tipica, Protectie OPP/OVP/SCP/OTP/OCP/UVP/SIP/NLO

Specificații tehnice 54 caracteristici
80 PLUS certification
80 PLUS Bronze
ATX power connector (20+4 pin)
Yes
ATX version
3.1
Bearing technology
HYB
Cabling type
Non-Modular
Certificare 80 Plus
80 PLUS Bronze
Certification
CE/FCC/CCC/RCM/EAC/CAN ICES-003(B)/NMB-003(B) /TUV-RH
Combined power (+3.3V)
100 W
Combined power (+5V)
100 W
Combined power (+5Vsb)
15 W
Combined power (-12V)
3.6 W
Compliance certificates
RoHS, WEEE
Cooling type
Active
Country of origin
China
CPU power connector (4+4 pin)
Yes
Efficiency
80Plus-Bronze
Fan diameter
12 cm
Fan location
Top
Hold time
16 ms
Iluminare RGB
Nu
Input current
8 - 4 A
Max output current (+3.3V)
20 A
Max output current (+5V)
20 A
Max output current (+5Vsb)
3 A
Max output current (-12V)
0.3 A
Mean time between failures (MTBF)
100000 h
Modular
Yes
Motherboard power cable length
55 cm
Motherboard power connector
20+4 pin ATX
Number of fans
1 fan(s)
Number of SATA power connectors
6
On/off switch
Yes
Operating temperature (T-T)
0 - 40 °C
Package type
Box
PCI Express power connectors (16-pin)
1
Peripheral (Molex) power connectors (4-pin)
2
PFC
Active
Power Factor Correction (PFC) type
Active
Power Good signal delay range
100 - 150 ms
Power supply unit (PSU) form factor
ATX
PSU Power
550 W
PSU Type
ATX
Purpose
PC
SATA power cable length
450,550,650 mm
Sustainability certificates
ErP, Triman
Sustainability compliance
Yes
TOTAL-POWER
550 W
Adâncime
140 mm
Lățime
150 mm
Înălțime
86 mm
Conectivitate wireless
Non Modular
Culoare
Black
Garanție comercială
60
Producător
DEEPCOOL
