HPE ProLiant DL145 Gen11 8124P 2.45GHz 16c 1P 2x32GB-R 2SFF

Lifecycle

• Obsolete Date 31-10-2027

Specifications

• Storage controller HPE NS204i-u Gen11 NVMe Hot Plug Boot Optimized Storage Device
• Expansion slots 1 x16 FHHL PCIe Gen5; 1 OCP 3.0 Slot as default
• Processor number 1 processor included
• Processor speed 2.45 GHz
• Memory type HPE DDR5 Smart Memory
• Processor cache 64 MB L3
• Processor core available 16 core
• Network controller Broadcom BCM5719 Ethernet 1Gb 4-port BASE-T OCP3 Adapter for HPE
• Form factor 2U Rack
• Warranty 3/3/3: Server Warranty includes three years of parts, three years of labor, and three years of on-site support coverage. Additional information regarding worldwide limited warranty and technical support is available at: https://support.hpe.com/hpesc/public/docDisplay?docId=sd00004309en_us. Additional HPE support and service coverage, to supplement the product warranty, is available. For more information, visit: https://www.hpe.com/support.
• Security TPM 2.0, silicon root of trust, secure boot, chassis intrusion detection and bezel lock, and Kensington lock, optional data-at-rest hardware encryption. For full security features refer to the QuickSpecs.
• Power supply type 2x HPE ProLiant 900W-1000W Flex Slot Titanium Hot Plug Reverse Air Flow AC Power Supply Kit
• Infrastructure management HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download), HPE iLO Advanced, HPE iLO Advanced Premium Security Edition, and HPE OneView Advanced (require licenses), HPE Compute Ops Management (subscription included). Refer to the iLO 6 User Guide
• Processor name AMD EPYC™ 8124P (16 core, 2.45 GHz, 64 MB L3, 125W)
• Included memory 64 GB (2×32 GB, 4800 MT/s)
• Included drives None ship standard, 2 SFF supported
• System fan features 4x Standard Fans

Quickspecs

• QuickSpecs (HTML)
• QuickSpecs
• QuickSpecs
• QuickSpecs (PDF)

Overview

Ready to experience exceptional performance, affordability, and versatility with a modern edge computing server solution? The HPE ProLiant DL145 Gen11 server is a 2U, single processor, robust edge computing server designed to cater to the needs of retail, manufacturing, telecommunications, and various other industries. It offers a compelling alternative to traditional servers with its sleek design, affordable pricing, and quiet operation.  Powered by the latest 5th Generation AMD® EPYC™ 8005 Zen5 architecture, this server provides up to 84 energy-efficient cores. PCIe Gen5 speed, and high-performance EDSFF storage. It can operate continuously in temperatures ranging from -5°C to 55°C and withstand high-dust and high-vibration environments. It is engineered for today's hybrid world, allowing enterprises to virtualize traditional IT applications to power their businesses and accelerate AI success.

What’s new

• AMD® EPYC™ 8004 (Siena) processor family, customized for edge computing and environments with physical constraints such as limited power, space, or cooling, 8 to 64 cores, TDP ratings of up to 200W.
• Compact size, 15 inches wide, 16 inches deep (without bezel), 20 inches (with bezel).
• Support for three single-wide or one double-wide GPUs.
• Various mounting option — Wall, desk, and rack.
• Operating temperature support up to to 55° C, bezel with air filter, designed to qualify for MIL-STD-810H.
• AMD® EPYC™ 8005 (Sorano) processor family, customized for edge computing and environments with physical constraints such as limited power, space, or cooling, 8 to 84 cores, TDP ratings of up to 225W.

Features

Keeping your Data and Property Safe with Enhanced Security Features

The HPE ProLiant DL145 Gen11 provides the high-quality security features needed to verify your peace of mind.

Hewlett Packard Enterprise cares about keeping your property and data safe, especially at the edge, where data and property are more vulnerable to attack.

Built on the Hewlett Packard Enterprise signature silicon root of trust, HPE iLO 6, IDevID, and platform certificates, you can be sure your data is being protected from outside threats.

Chassis Intrusion detection with bezel and Kensington locks keep your device safe from unwarranted theft or intrusions.

The HPE ProLiant DL145 leverages a 2U form factor, providing better cooling operation, airflow, and quiet acoustics.

Measuring approximately 15 inches wide and 16 inches deep, the HPE ProLiant DL145 Gen11 can be rack, wall, or desk mounted, providing flexibility for your unique business environment.

Built for tough edge environments, the system is designed to operate reliably at temperatures up to 55°C and withstand shock and vibration. With the optional Military Ruggedization Kit, it is validated to MIL‑STD‑810H standards, delivering additional durability in harsh deployment conditions.

In locations with heavy amounts of dust and debris, the large air filter of the HPE ProLiant DL145 Gen11 is able to filter out harmful airborne material, keeping your device running efficiently.

The server supports up to 84 cores and offers support for 3x single wide or 1x double wide GPUs, customizing its performance for edge workloads while simultaneously delivering more energy efficiency through new EDSFF performance drives.

Additionally, the HPE Integrated Lights Out (iLO) and HPE Compute Ops Management allow for ease of management in a variety of locations. The HPE ProLiant DL145 Gen11 small server footprint puts sustainability efforts top of mind for users.

Customized for Diverse Portfolio of Edge Computing Environments
Get Robust Edge Processing Power with a Small Server Footprint

The HPE ProLiant DL145 Gen11 reduces the reliance on cloud infrastructure by tackling a variety of low-latency workloads with efficient processing powered by AMD Sorano and Siena processors.

Media

The new HPE ProLiant DL145 Gen11 | Chalk Talk

Learn how to energize your enterprise edge compute with the new HPE ProLiant DL145 Gen11. It is a compact, affordable, yet powerful edge server designed to support critical business applications, virtualization and AI workloads.

Energize your enterprise with edge computing

The HPE ProLiant DL145 Gen11 with 4th Gen AMD EPYC 8004 processor, extends the HPE ProLiant Gen11 edge server portfolio that support a range of industry apps such inventory management, pricing / point of sale.

HPE ProLiant DL145 Gen11 Product Tour

Animated product tour of the HPE ProLiant DL145 Gen11 server.

Compatible products

• HPE 1.92T NVMERI SFF BC U.3ST V2 MV SSD
• HPE MR416I-P GEN11 SPDM STORAGE CNTLR
• Broadcom BCM57504 Ethernet 10/25Gb 4-port SFP28 Adapter for HPE
• HPE Bezel Lock Kit
• HPE 480GB SATA 6G Read Intensive SFF BC Multi Vendor SSD
• HPE 480GB SATA 6G Mixed Use SFF BC Multi Vendor SSD
• HPE 7.68T NVMERI SFF BC U.3ST V2 MV SSD
• BCM 57414 10/25GbE 2p SFP28 Adptr
• HP OV 3yr 24×7 Supp Flex E-LTU
• HPE 3.84TB SATA 6G Read Intensive SFF BC Multi Vendor SSD
• HPE MR408i-o Gen11 x8 Lanes 4GB Cache OCP SPDM Storage Controller
• HPE 1.92TB SATA 6G Mixed Use SFF BC Multi Vendor SSD
• Broadcom BCM5719 Ethernet 1Gb 4-port BASE-T Adapter for HPE
• HPE 96W Smart Storage Lithium-ion Battery with 145mm Cable Kit
• HPE 3 Year Tech Care Essential DL145 Gen11 Smart Choice Service
• HPE 1.92TB SATA 6G Read Intensive SFF BC Multi Vendor SSD
• HPE 960GB SATA 6G Mixed Use SFF BC Multi Vendor SSD
• HPE iLO Advanced Electronic License with 3yr Support on iLO Licensed Features
• HPE Proliant DL/ML Startup Service
• HPE Proliant DL/ML Install Service
• HPE 5 Year Tech Care Essential DL145 Gen11 Smart Choice Service
• Broadcom BCM5719 Ethernet 1Gb 4-port BASE-T OCP3 Adapter for HPE
• MLX MCX631102 10/25GBE 2P SFP28 ADPTR
• HPE 960GB SATA 6G Read Intensive SFF BC Multi Vendor SSD
• HPE 5 Year Tech Care Basic DL145 Gen11 Smart Choice Service
• HPE iLO Advanced 1-server License with 3yr Support on iLO Licensed Features
• HPE 32GB (1x32GB) Dual Rank x8 DDR5-4800 CAS-40-39-39 EC8 Registered Smart Memory Kit
• HPE MR216i-p Gen11 x16 Lanes without Cache PCI SPDM Plug-in Storage Controller
• HPE 64GB (1x64GB) Dual Rank x4 DDR5-4800 CAS-40-39-39 EC8 Registered Smart Memory Kit
• HPE DL38X Gen10 Plus 2U Cable Management Arm for Rail Kit
• HPE iLO Advanced 1-server License with 1yr Support on iLO Licensed Features
• Broadcom BCM57416 Ethernet 10Gb 2-port BASE-T OCP3 Adapter for HPE
• Broadcom BCM57416 Ethernet 10Gb 2-port BASE-T Adapter for HPE
• BCM 57412 10GBE 2P SFP+ OCP3 ADPTR
• Broadcom BCM57412 Ethernet 10Gb 2-port SFP+ Adapter for HPE
• HPE OV for DL 3y 24×7 Bdl Track 1Svr Lic
• HPE 3 Year Tech Care Basic DL145 Gen11 Smart Choice Service
• HPE iLO Advanced Electronic License with 1yr Support on iLO Licensed Features
• Intel I350-T4 Ethernet 1Gb 4-port BASE-T OCP3 Adapter for HPE
• HPE NS204i-u Gen11 NVMe Hot Plug Boot Optimized Storage Device

Documents

• HPE ProLiant DL145 Gen11 QuickSpecs
• Enterprise server acceleration from edge to data center

[1]Typical NEBS certification is 90 days post production manufacture
