Placa de baza Biostar A520MHP, Socket AM4, DDR4, Micro-ATX

Placi de baza

Placa de baza Biostar A520MHP, Socket AM4, DDR4, Micro-ATX

(0) Stoc epuizat
Vândut de RITC.ro Cod produs: A520MHP

Livrare și beneficii

Livrare rapidă 24–48 ore prin curier Livrare rapidă Retur gratuit în 30 de zile Retur 30 de Garanție inclusă 24 luni garanție oficială Garanție 24 luni

Compară cu produse similare

Vezi comparația completă
Caracteristică Placa de baza Biostar A520MHP, Socket AM4, DDR4, Micro-ATX Placa de bază ASUS PRIME H610M-R D4 LGA1700 Placa de baza ASUS Z13PE-D16/ASMB11, Socket LGA 4677, DDR5, E-ATX Placa de baza Gigabyte Z890 AORUS ELITE DUO X, LGA Placa de baza Gigabyte B550 AORUS ELITE WIFI7, Socket AM4,
Alte caracteristici
1st M.2 highest PCI Express generation — — — 5.0 4.0
1st M.2 largest key size — — — 25110 22110
2nd M.2 highest PCI Express generation — — — 4.0 3.0
2nd M.2 largest key size — — — 22110 22110
12V power connector — Yes — Yes Yes
ACPI version — — — 5.0 5.0
Antenna included — — — Yes Yes
ATX Power connector (24-pin) Yes Yes Yes Yes Yes
Audio Chip Realtek ALC897 — — Realtek ALC1220 Realtek ALC897
Audio connector Yes Yes — — —
Audio output channels 7.1 channels 7.1 channels — 7.1 channels 7.1 channels
Batteries included — — — Yes Yes
Battery-Capacity — — — 220 mAh 220 mAh
Battery technology — — — Lithium-Manganese Dioxide (LiMnO2) Lithium-Manganese Dioxide (LiMnO2)
Battery type — — — CR2032 CR2032
Battery weight — — — 3 g 3 g
BIOS memory size — 128 Mbit — 512 Mbit 128 Mbit
BIOS type UEFI UEFI AMI — UEFI AMI UEFI AMI
Bluetooth No Nu Nu Yes Yes
Bundled software BullGuard (90 days FREE trial) — — Norton® Internet Security (OEM version) Norton® Internet Security (OEM version)
Canale audio 7.1 7.1 N/A 7.1 7.1
Chipset audio integrat Realtek Realtek Realtek Realtek Realtek
Clear CMOS jumper — Yes — Yes —
Compatible processor series AMD Ryzen 3000 Series, AMD Ryzen 4000 Series, AMD Ryzen 5000 Series — Intel® Xeon® Intel Core Ultra (Series 2) AMD Ryzen 5000 Series, AMD Ryzen 4000 Series, AMD Ryzen 3000 Series
Component for PC PC Server PC PC
Cooling type — — — Passive Passive
Country of origin — — — China China
CPU fan connector Yes Yes — Yes Yes
Depth 190 mm 193 mm 330.2 mm 305 mm 305 mm
Desktop Management Interface (DMI) version — — — 2.7 2.7
Digital audio optical out — — — 1 1
DirectX version 12.0 — — 12.0 12.0
DisplayPorts quantity — — — 1 1
DisplayPort version — — — 2.1 1.4
ECC сompatibility Non-ECC Non-ECC — ECC & Non-ECC ECC & Non-ECC
EPS power connector (8-pin) — — Yes Yes Yes
Ethernet interface type Gigabit Ethernet Gigabit Ethernet 10 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet 5 Gigabit Ethernet, 2.5 Gigabit Ethernet, Gigabit Ethernet, Fast Ethernet 2.5 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet
Ethernet LAN (RJ-45) ports — — 2 1 1
Format Micro-ATX Micro-ATX E-ATX ATX ATX
Front panel audio connector Yes Yes — Yes Yes
Front panel connector Yes — — Yes Yes
Gaming Nu Nu Nu Nu Nu
HDCP Yes — — Yes Yes
HDCP version — — — 2.3 2.3
HDMI Da Da Nu Nu Da
HDMI version — 2.1 — — 2.1
Headphone outputs 1 3 — 1 1
Height — — — 35 mm 35 mm
LAN controller Realtek RTL8111H — Intel X710-AT2 Realtek RTL8126 Realtek RTL8125
Line-in Yes — — Yes Yes
Lithium weight per battery — — — 0.07 g 0.07 g
MAXIMUM-RESOLUTION — 3840 x 2160 pixels — 4096 x 2304 pixels 5120 x 2880 pixels
Maximum internal memory per slot — — — 128 GB 32 GB
MB-Format micro-ATX micro-ATX — ATX ATX
MB-Socket AM4 1700 — AM5 AM4
Memorie maxima 64 GB 64 GB 2 TB 256 GB 128 GB
Memory channels Dual-channel — Octa-channel Dual-channel Dual-channel
Memory slots type SO-DIMM DIMM DIMM DIMM DIMM
Microphone in Yes Yes — — Yes
Model Chipset A520 H610 C741 Z890 B550
Motherboard chipset AMD A520 Intel H610 Intel C741 Intel Z890 Express AMD B550
Motherboard chipset family AMD Intel Intel Intel AMD
Motherboard form factor micro ATX micro ATX Extended ATX ATX ATX
Numar sloturi memorie 2 2 16 2 4
Number of battery cells — — — 1 1
Number of chassis fan connectors — 1 — 4 3
Number of CPU fan connectors — — — 2 2
Number of EPS power connectors (8-pin) — — — 2 1
Number of HDDs supported 4 — 10 4 4
Number of M.2 (M) slots — 1 2 5 2
Number of memory slots 2 2 16 2 4
Number of RGB LED pin headers — — — 4 5
Number of SATA III connectors 4 4 10 4 4
Number of storage drives supported 1 5 — 9 6
Number of water pump connectors — — — 2 1
Onboard-CPU No No — No No
Package depth — — — 294 mm 270 mm
Package height — — — 80 mm 80 mm
Package weight — — 2.75 kg 3.05 kg 1.92 kg
Package width — — — 345 mm 335 mm
Parallel processing technology support — — — Not supported Not supported
PC health monitoring — — — Fan, Temperature, Voltage, Water cooling Fan, LED, Temperature, Voltage, Water cooling
PCI-Ex1 2 — — 1 1
PCI-Ex16 1 1 — 4 3
PCI Express x1 (Gen 3.x) slots 2 1 — — 1
PCI Express x16 (Gen 4.x) slots — 1 — 2 1
PCI Express x16 (Gen 5.x) slots — — 5 1 —
Power source type ATX — — ATX ATX
Processor socket Socket AM4 LGA 1700 LGA 4677 (Socket E) LGA 1851 (Socket V1) Socket AM4
Products per shipping (inner) case — — — 1 pc(s) 1 pc(s)
PS/2 ports quantity 1 2 — — —
RAID levels 0, 1, 10 — — 0, 1, 5, 10 0, 1, 10
RAID support Yes — — Yes Yes
RAM-Slots 2 2 — 4 4
RGB LED pin header — — — Yes Yes
RJ-45 LAN 1 1 2 1 1
S/PDIF out port — — — Yes Yes
Screws included — — — Yes Yes
Serial-or-Paralel No/No No/No — Yes/No No/No
Sloturi M.2 1 1 2 5 2
Soclu Procesor Socket AM4 Socket 1700 Socket LGA 4677 Socket 1851 Socket AM4
Supported memory clock speeds 2133,2400,2667,2933,3200,3600,3800,4000,4133,4266,4400 MHz 2133,2400,2666,2800,2933,3000,3200 MHz 4800,5600 MHz 10266 MHz 4733,4600,4400,4266,4133,4000,3866,3733,3600,3466,3400,3200,2933,2667,2400,2133 MHz
Supported memory module capacities 8GB, 16GB, 32GB — 16GB, 32GB, 64GB, 128GB — —
Supported memory types DDR4-SDRAM DDR4-SDRAM DDR5-SDRAM DDR5-SDRAM DDR4-SDRAM
Supported processor sockets Socket AM4 LGA 1700 — LGA 1851 Socket AM4
Supported storage drive interfaces M.2, PCI Express 3.0, SATA III M.2, SATA III M.2, SATA III PCI Express 5.0, PCI Express 4.0, NVMe, M.2, SATA III M.2, PCI Express 4.0, PCI Express 3.0, SATA III
Supported storage drive types HDD & SSD HDD & SSD HDD & SSD HDD & SSD HDD & SSD
System Management BIOS (SMBIOS) version — — — 2.7 2.7
Thunderbolt Nu Nu Nu Nu Nu
Tip Memorie DDR4 DDR4 DDR5 DDR5 DDR4
Tip slot interfata grafica PCIe 3.0 x16 PCIe 4.0 x16 PCIe 5.0 x16 PCIe 5.0 x16 PCIe 4.0 x16
TPM connector — Yes Yes Yes —
Unbuffered memory — Yes — Yes Yes
USB 2.0 connectors 2 2 1 2 2
USB3 2 4-8 — 4-8 4-8
USB 3.2 Gen 1 (3.1 Gen 1) connectors 1 1 1 1 2
USB Type-C N/A Da N/A N/A N/A
VGA (D-Sub) ports quantity 1 1 1 — —
Video-Connection VGA/HDMI VGA/DVI/HDMI — HDMI/DP HDMI/DP
Wi-Fi No — — Yes Yes
Width 235 mm 226 mm 304.8 mm 244 mm 244 mm
WiFi-AP antenna jack — — — 2 2
Windows operating systems supported Windows 10, Windows 11 Windows 10 x64, Windows 11 x64 — Windows 11 Windows 11
Wireless Nu Nu N/A Da Da
WLAN controller model — — — Intel Wi-Fi 7 BE200 Realtek RTL8922AE
Laptopuri - Conectivitate
Rețea prin cablu (LAN) Yes — Yes Yes Yes
Standard Wi-Fi — — — Wi-Fi 7 (802.11be) Wi-Fi 7 (802.11be)
Versiune Bluetooth — — — 5.4 5.4
Laptopuri - Construcție
Culoare — — — Black Black
Greutate — 842 g 1.75 kg 2.63 kg 1.68 kg
Laptopuri - Generale
Garanție comercială 24 36 24 36 36
Producător BIOSTAR ASUS ASUS GIGABYTE GIGABYTE
Laptopuri - Memorie
Memorie RAM maximă 64 GB — 2 TB 256 GB 128 GB
Laptopuri - Porturi
Număr porturi USB 2.0 4 2 — 4 2
Porturi HDMI 1 — — — 1
Laptopuri - Procesor
Producător procesor AMD — Intel Intel AMD

Analiză inteligentă a produsului

În curând vei putea afla mai multe informații despre produs, generate cu inteligență artificială.

Descriere oficială

Placa de Baza BIOSTAR A520MHP AM4, 2x DDR4, 1x VGA 1x HDMI, 1x M.2, 2x PCIE 3.0 x16 2x PCIE 3.0 x1, 4x SATA 6GB/s, mATX

Specificații tehnice 83 caracteristici
ATX Power connector (24-pin)
Yes
Audio Chip
Realtek ALC897
Audio connector
Yes
Audio output channels
7.1 channels
BIOS type
UEFI
Bluetooth
No
Bundled software
BullGuard (90 days FREE trial)
Canale audio
7.1
Chipset audio integrat
Realtek
Compatible processor series
AMD Ryzen 3000 Series, AMD Ryzen 4000 Series, AMD Ryzen 5000 Series
Component for
PC
CPU fan connector
Yes
Depth
190 mm
DirectX version
12.0
ECC сompatibility
Non-ECC
Ethernet interface type
Gigabit Ethernet
Format
Micro-ATX
Front panel audio connector
Yes
Front panel connector
Yes
Gaming
Nu
HDCP
Yes
HDMI
Da
Headphone outputs
1
LAN controller
Realtek RTL8111H
Line-in
Yes
MB-Format
micro-ATX
MB-Socket
AM4
Memorie maxima
64 GB
Memory channels
Dual-channel
Memory slots type
SO-DIMM
Microphone in
Yes
Model Chipset
A520
Motherboard chipset
AMD A520
Motherboard chipset family
AMD
Motherboard form factor
micro ATX
Numar sloturi memorie
2
Number of HDDs supported
4
Number of memory slots
2
Number of SATA III connectors
4
Number of storage drives supported
1
Onboard-CPU
No
PCI-Ex1
2
PCI-Ex16
1
PCI Express x1 (Gen 3.x) slots
2
PCI Express x16 slots
1
Power fan connector
Yes
Power source type
ATX
Processor socket
Socket AM4
PS/2 ports quantity
1
RAID levels
0, 1, 10
RAID support
Yes
RAM-Slots
2
RJ-45 LAN
1
Serial-or-Paralel
No/No
Sloturi M.2
1
Soclu Procesor
Socket AM4
Supported memory clock speeds
2133,2400,2667,2933,3200,3600,3800,4000,4133,4266,4400 MHz
Supported memory module capacities
8GB, 16GB, 32GB
Supported memory types
DDR4-SDRAM
Supported processor sockets
Socket AM4
Supported storage drive interfaces
M.2, PCI Express 3.0, SATA III
Supported storage drive types
HDD & SSD
Thunderbolt
Nu
Tip Memorie
DDR4
Tip slot interfata grafica
PCIe 3.0 x16
USB 2.0 connectors
2
USB3
2
USB 3.2 Gen 1 (3.1 Gen 1) connectors
1
USB Type-C
N/A
VGA (D-Sub) ports quantity
1
Video-Connection
VGA/HDMI
Wi-Fi
No
Width
235 mm
Windows operating systems supported
Windows 10, Windows 11
Wireless
Nu
Rețea prin cablu (LAN)
Yes
Garanție comercială
24
Producător
BIOSTAR
Memorie RAM maximă
64 GB
Număr porturi USB 2.0
4
Număr USB-A 3.2 Gen 1
2
Porturi HDMI
1
Producător procesor
AMD
