Placa de baza Sapphire A520M-E, Socket AM4, DDR4, Micro-ATX

Placi de baza

Placa de baza Sapphire A520M-E, Socket AM4, DDR4, Micro-ATX

(0) Stoc epuizat
Vândut de RITC.ro Cod produs: 52119-04-40G

Livrare și beneficii

Livrare rapidă 24–48 ore prin curier Livrare rapidă Retur gratuit în 30 de zile Retur 30 de Garanție inclusă 24 luni garanție oficială Garanție 24 luni

Compară cu produse similare

Vezi comparația completă
Caracteristică Placa de baza Sapphire A520M-E, Socket AM4, DDR4, Micro-ATX Placa de bază ASUS PRIME H610M-R D4 LGA1700 Placa de baza ASUS Z13PE-D16/ASMB11, Socket LGA 4677, DDR5, E-ATX Placa de baza Gigabyte B550M AORUS ELITE, Socket AM4, DDR4, Placa de baza Gigabyte B850 GAMING WIFI6, Socket AM5, DDR5,
Alte caracteristici
1st M.2 highest PCI Express generation 3.0 — — — 5.0
1st M.2 largest key size 2280 — — — 25110
12V power connector — Yes — Yes Yes
ACPI version — — — 5.0 5.0
ATX Power connector (24-pin) Yes Yes Yes Yes Yes
Audio Chip Realtek ALC897 — — Realtek ALC887 Realtek ALC897
Audio connector Yes Yes — — —
Audio output channels 5.1 channels 7.1 channels — 7.1 channels 7.1 channels
Battery technology — — — Lithium-Manganese Dioxide (LiMnO2) Lithium-Manganese Dioxide (LiMnO2)
Battery type — — — CR2032 CR2032
Battery weight — — — 3 g 3 g
BIOS memory size — 128 Mbit — 256 Mbit 256 Mbit
BIOS type — UEFI AMI — UEFI AMI UEFI AMI
Cables included — SATA — SATA —
Canale audio N/A 7.1 N/A 7.1 7.1
Chipset audio integrat Realtek Realtek Realtek Realtek Realtek
Clear CMOS button — — — Yes Yes
Clear CMOS jumper Yes Yes — Yes Yes
Compatible processor series AMD Ryzen 3000 Series, AMD Ryzen 4000 Series, AMD Ryzen 5000 Series — Intel® Xeon® AMD Ryzen 3000 Series, AMD Ryzen Threadripper 3000 Series, AMD Ryzen Threadripper PRO 3000 WX-Series AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
Component for PC PC Server PC PC
Country of origin — — — China China
CPU fan connector Yes Yes — Yes Yes
Desktop Management Interface (DMI) version — — — 2.7 2.7
DirectX version — — — 12.0 12.0
Drivers included — Yes — Yes —
DVI-D ports quantity — 1 — 1 —
ECC сompatibility — Non-ECC — ECC & Non-ECC Non-ECC
EPS power connector (8-pin) — — Yes — Yes
Ethernet interface type Gigabit Ethernet Gigabit Ethernet 10 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet Gigabit Ethernet Gigabit Ethernet
Ethernet LAN (RJ-45) ports 1 — 2 — —
Format Micro-ATX Micro-ATX E-ATX Micro-ATX ATX
Front panel audio connector — Yes — Yes Yes
Front panel connector Yes — — Yes Yes
Gaming Nu Nu Nu Da Da
Harmonized System (HS) code — 84733020 — 84733020 —
HDCP — — — Yes Yes
Headphone outputs 3 3 — 1 1
Lithium weight per battery — — — 0.07 g 0.07 g
MAXIMUM-RESOLUTION — 3840 x 2160 pixels — 4096 x 2160 pixels 4096 x 2160 pixels
Maximum internal memory per slot 32 GB — — — 64 GB
MB-Format micro-ATX micro-ATX — micro-ATX ATX
MB-Socket AM4 1700 — AM4 AM5
Memorie maxima N/A 64 GB 2 TB 128 GB 256 GB
Memory slots type DIMM DIMM DIMM DIMM DIMM
Microphone in Yes Yes — Yes Yes
Model Chipset A520 H610 C741 B550 B850
Motherboard chipset AMD A520 Intel H610 Intel C741 AMD B550 AMD B850
Motherboard chipset family AMD Intel Intel AMD AMD
Motherboard form factor micro ATX micro ATX Extended ATX micro ATX ATX
Numar sloturi memorie 2 2 16 4 4
Number of chassis fan connectors 1 1 — 2 3
Number of CPU fan connectors 1 — — — 2
Number of HDDs supported — — 10 4 4
Number of M.2 (M) slots 1 1 2 2 3
Number of memory slots 2 2 16 4 4
Number of SATA III connectors 4 4 10 4 4
Number of storage drives supported 5 5 — 6 7
Onboard-CPU Yes No — — No
Package depth — — — 265 mm 270 mm
Package height — — — 65 mm 80 mm
Package weight — — 2.75 kg 1.27 kg 1.76 kg
Package width — — — 265 mm 335 mm
Parallel processing technology support Not supported — — Not supported Not supported
PC health monitoring — — — CPU, Fan, LED, Power supply, Temperature, Voltage Fan, Temperature, Voltage, Water cooling
PCI-Ex1 1 — — 1 —
PCI-Ex16 1 1 — 1 3
PCI Express x1 (Gen 3.x) slots 1 1 — 1 —
PCI Express x16 (Gen 3.x) slots 1 — — — 3
PCI Express x16 (Gen 5.x) slots — — 5 — 1
Power source type — — — ATX ATX
Processor socket Socket AM4 LGA 1700 LGA 4677 (Socket E) Socket AM4 Socket AM5
PS/2 ports quantity 1 2 — 1 —
RAID levels — — — 0, 1, 10 0, 1, 10
RAM-Slots 2 2 — 4 4
RGB LED pin header — — — Yes Yes
RJ-45 LAN N/A 1 2 1 1
Serial-or-Paralel — No/No — No/No No/No
Serial port headers — — — 1 1
Serial ports quantity — — 1 1 —
Sloturi M.2 N/A 1 2 2 3
Soclu Procesor Socket AM4 Socket 1700 Socket LGA 4677 Socket AM4 Socket AM5
Supported memory clock speeds 3200 MHz 2133,2400,2666,2800,2933,3000,3200 MHz 4800,5600 MHz 4733 MHz 8200 MHz
Supported memory module capacities — — 16GB, 32GB, 64GB, 128GB 1GB, 2GB, 4GB, 16GB, 32GB —
Supported memory types DDR4-SDRAM DDR4-SDRAM DDR5-SDRAM DDR4-SDRAM DDR5-SDRAM
Supported processor sockets Socket AM4 LGA 1700 — Socket AM4 Socket AM5
Supported storage drive interfaces PCI Express 3.0, SATA III M.2, SATA III M.2, SATA III M.2, SATA III M.2, SATA III
Supported storage drive types HDD & SSD HDD & SSD HDD & SSD HDD & SSD HDD & SSD
System Management BIOS (SMBIOS) version — — — 2.7 2.7
Tip Memorie DDR4 DDR4 DDR5 DDR4 DDR5
Tip slot interfata grafica N/A PCIe 4.0 x16 PCIe 5.0 x16 PCIe 4.0 x16 N/A
TPM connector — Yes Yes Yes Yes
Unbuffered memory — Yes — Yes Yes
USB 2.0 connectors 1 2 1 1 2
USB3 1 4-8 — 4-8 4-8
USB 3.2 Gen 1 (3.1 Gen 1) connectors 1 1 1 1 1
VGA (D-Sub) ports quantity 1 1 1 — —
Video-Connection VGA/HDMI VGA/DVI/HDMI — DVI/HDMI HDMI/DP
Wi-Fi No — — No Yes
Windows operating systems supported Windows 10 x64, Windows 11 x64 Windows 10 x64, Windows 11 x64 — Windows 10 x64, Windows 11 x64 Windows 10 x64, Windows 11 x64
Wireless N/A Nu N/A Nu Da
Caracteristici fizice
Greutate — 842 g 1.75 kg — 1.51 kg
Conectivitate
Tip conector USB USB Type-A USB Type-A — USB Type-A —
Laptopuri - Baterie 25.09
Număr celule baterie — — — 1 1
Laptopuri - Caracteristici fizice 25.09
Adâncime 19.7 mm 193 mm 330.2 mm 24.4 mm 24.4 mm
Lățime 230 mm 226 mm 304.8 mm 244 mm 30.5 mm
Înălțime — — — 35 mm 35 mm
Laptopuri - Conectivitate și porturi 25.09
Bluetooth Nu Nu Nu Nu Da
HDMI Da Da Nu Da Da
Număr porturi HDMI 1 — — 1 1
Număr porturi USB 2.0 2 2 — 4 4
Porturi USB-A 3.2 Gen 1 4 — — 4 —
Rețea prin cablu (LAN) Yes — Yes Yes Yes
Thunderbolt Nu Nu Nu Nu Nu
USB-C N/A Da N/A Da Da
Versiune HDMI — 2.1 — 2.1 —
Laptopuri - Construcție
Culoare Black — — Brown Brown
Laptopuri - Generale
Garanție comercială 24 36 24 36 36
Producător SAPPHIRE ASUS ASUS GIGABYTE GIGABYTE
Laptopuri - Memorie RAM 25.09
Canale memorie RAM Dual-channel — Octa-channel Dual-channel Dual-channel
Memorie RAM maximă 64 GB — 2 TB 128 GB 256 GB
Laptopuri - Procesor
Producător procesor AMD — Intel AMD AMD

Analiză inteligentă a produsului

În curând vei putea afla mai multe informații despre produs, generate cu inteligență artificială.

Descriere oficială

Placa de baza SAPPHIRE A520M-E, Socket AM4, mATX

Specificații tehnice 109 caracteristici
1st M.2 highest PCI Express generation
3.0
1st M.2 largest key size
2280
Alte specificatii
1x PCIe 3.0 x4
ATX Power connector (24-pin)
Yes
Audio Chip
Realtek ALC897
Audio connector
Yes
Audio jacks
3
Audio output channels
5.1 channels
Canale audio
N/A
Capacitate maxima memorie RAM
64 GB
Chipset
A520
Chipset audio
Realtek ALC897
Chipset audio integrat
Realtek
Chipset retea
Realtek RTL8111M
Clear CMOS jumper
Yes
Compatible processor series
AMD Ryzen 3000 Series, AMD Ryzen 4000 Series, AMD Ryzen 5000 Series
Component for
PC
CPU fan connector
Yes
Dimensiuni (L x l, cm)
23 × 19.7 cm
Ethernet interface type
Gigabit Ethernet
Ethernet LAN (RJ-45) ports
1
Format
Micro-ATX
Front panel connector
Yes
Gaming
Nu
Header USB 3.0
Da
Headphone outputs
3
Interfata grafica
PCI Express x16 3.0
Maximum internal memory per slot
32 GB
MB-Format
micro-ATX
MB-Socket
AM4
Memorie maxima
N/A
Memorie Suportata
DDR4
Memory slots type
DIMM
Microphone in
Yes
Model Chipset
A520
Motherboard chipset
AMD A520
Motherboard chipset family
AMD
Motherboard form factor
micro ATX
NGFF (M.2)
1
Numar sloturi memorie
2
Number of chassis fan connectors
1
Number of CPU fan connectors
1
Number of M.2 (M) slots
1
Number of memory slots
2
Number of SATA III connectors
4
Number of storage drives supported
5
Onboard-CPU
Yes
Parallel processing technology support
Not supported
PCI
2
PCI-Ex1
1
PCI-Ex16
1
PCI Express 3.0
1 (x16)1 (x4)
PCI Express x1 (Gen 3.x) slots
1
PCI Express x16 (Gen 3.x) slots
1
Placa audio integrata
5.1 Audio
Placa retea integrata
1 Gbps
Placa video Integrata
Necesita procesor cu tehnologia AMD Radeon Graphics
Procesoare suportate
AMD Ryzen 3000/4000/5000 Series
Processor socket
Socket AM4
Producator chipset
AMD
PS/2 Combo Mouse/Tastatura
1
PS/2 ports quantity
1
RAM-Slots
2
Recomandat Gaming
Da
RJ-45
1
RJ-45 LAN
N/A
SATA III
4
Sloturi M.2
N/A
Sloturi memorie
2
Socket procesor
AM4
Soclu Procesor
Socket AM4
Suport audio
5.1
Supported memory clock speeds
3200 MHz
Supported memory types
DDR4-SDRAM
Supported processor sockets
Socket AM4
Supported storage drive interfaces
PCI Express 3.0, SATA III
Supported storage drive types
HDD & SSD
Tehnologie
Dual Channel
Tip Memorie
DDR4
Tip slot interfata grafica
N/A
USB 2.0
2
USB 2.0 connectors
1
USB3
1
USB 3.2 Gen 1 (3.1 Gen 1) connectors
1
USB 3.2 Gen1 tip A
4
VGA
1
VGA (D-Sub) ports quantity
1
Video-Connection
VGA/HDMI
Wi-Fi
No
Windows operating systems supported
Windows 10 x64, Windows 11 x64
Wireless
N/A
Tip conector USB
USB Type-A
Adâncime
19.7 mm
Lățime
230 mm
Bluetooth
Nu
DisplayPort
1
HDMI
Da
Număr porturi HDMI
1
Număr porturi USB 2.0
2
Porturi USB-A 3.2 Gen 1
4
Rețea prin cablu (LAN)
Yes
Thunderbolt
Nu
USB-C
N/A
Culoare
Black
Garanție comercială
24
Producător
SAPPHIRE
Canale memorie RAM
Dual-channel
Memorie RAM maximă
64 GB
Producător procesor
AMD
