HPE Networking CX6100 24G Class4 PoE 4SFP+ 370W Switch

Switchuri

HPE Networking CX6100 24G Class4 PoE 4SFP+ 370W Switch

(0) În stoc
Vândut de RITC.ro Cod produs: JL677A

Livrare și beneficii

Livrare rapidă 24–48 ore prin curier Livrare rapidă Retur gratuit în 30 de zile Retur 30 de Garanție inclusă 24 luni garanție oficială Garanție 24 luni Garanție producător De confirmat Producător: De confirmat

Compară cu produse similare

Vezi comparația completă
Caracteristică HPE Networking CX6100 24G Class4 PoE 4SFP+ 370W Switch HPE Aruba Networking CX 6000 24G Class4 PoE 4SFP 370W Switch HPE Networking Instant On Switch 40p Gigabit CL4 8p Gigabit CL6 PoE 2p 10GBT 2p SFP+ 600W 1960 Switch ZYXEL GS-1900-24 v2, Gigabit, 24 porturi Switch Hikvision Fast Ethernet DS-3E0105D-O, 5 porturi
Culoare produs — — — Black Black, White
Basic switching RJ-45 Ethernet ports type — — — 24, Gigabit Ethernet (10/100/1000) 5, Fast Ethernet (10/100)
MAC address auto-learning supported — — — Yes Yes
MAC address table — — — 8000 entries 2000 entries
Power consumption (max) — — — 16 W 3 W
Storage temperature (T-T) — — — -40 - 70 °C -40 - 85 °C
Store-and-forward — — — Yes Yes
Greutate — — — 2.09 kg 93 g
Management — — — Da nu
Montare in rack — — — Da Nu
PoE — — — Nu Nu
Porturi RJ 45 — — — 24-28 5-10
Porturi SFP — — — 1-2 N/A
Viteză transfer — — — Gigabit Fast Ethernet
Sursă inclusă — — — Yes Yes
Sursă de alimentare — — — AC DC
Capacitate switching — — — 52 Gbit/s 1 Gbit/s
Montare rack — — — Yes No
Rată forwarding — — — 39 Mpps 0.74 Mpps
Stivuibil — — — Yes No
Suport 10G — — — No No
Adâncime — — — 131 mm 52 mm
Lățime — — — 440 mm 83 mm
Înălțime — — — 44 mm 22 mm
Viteză rețea LAN — — — 10,100,1000 Mbit/s 10,100 Mbit/s
Producător ARUBA NETWORKS ARUBA NETWORKS ARUBA NETWORKS ZYXEL HIKVISION

Analiză inteligentă a produsului

În curând vei putea afla mai multe informații despre produs, generate cu inteligență artificială.

Descriere oficială

Lifecycle

  • Obsolete Date 31-12-2099
  • End of support date 31-12-2104

Specifications

  • Operating temperature Maximum of 32°F to 113°F (0°C to 45°C) up to 5000 ft (1.5 km) derate by 1°C for every 1000 ft (305m) from 5000 ft (1.5 km) to 10000 ft (3.0 km)
  • Throughput 95.2 Mpps
  • Memory and processor Dual Core ARM Cortex A9 @ 1016 Mhz 4 GB DDR3, maximum, depending on model 16 GB eMMC
  • Latency 1 Gbps: 1.5 μSec, 10 Gbps: 1.8 μSec
  • Ports 24x 10/100/1000BASE-T ports 4x 1G/10G SFP ports Supports PoE standards IEEE 802.3af, 802.3at 1x USB-C console port 1x USB Type-A host port
  • Warranty Limited lifetime warranty. See the warranty duration.
  • Power consumption Max. Power (w/o PoE): 32.7W Max. Power (w/ PoE): 455W
  • PoE capability 370W Class 4 PoE/PoE+
  • Input voltage 100–127 VAC / 200–240 VAC
  • Switching capacity 128 Gbps
  • Management features Management flexibility with support for HPE Aruba Networking Central, easy-to-use Web GUI, CLI, and HPE Networking Switch Multi-Edit Software
  • Power supply Fixed power supply
  • Fans Fixed fans

Quickspecs

Overview

The HPE Networking CX6100 Switch Series is a modern family of entry-level access switches ideal for branch offices, mid-market enterprises, and larger SMB networks. Designed for reliable, simple, and secure access, this switch family provides a convenient wired access solution for enterprise networks supporting Internet of Things (IoT), mobile, and cloud applications. Prepare your network for future demands with a powerful ASIC and the programmable HPE Networking CX Switch Operating System (OS-CX) to deliver a more consistent, more efficient operator experience. This Layer 2 switch series has convenient built-in high speed uplinks with up to 740W of IEEE 802.3at Class 4 PoE to support IoT devices such as security cameras and wireless APs. A compact and fanless 12-port model is ideal for use in quiet workspaces. With robust quality of service (QoS), support for static routing, and IPv6, these switches also simplify ownership with no switch software licensing requirements.

What’s new

  • The CX6100 series provides right size with 12, 24, and 48-port 1U models with convenient built-in 1/10GbE uplinks and up to 740W of Class 4 PoE
  • It offers scalability with a 6-member switch virtual switching framework (VSF) stacking
  • It has compact and fanless 12-port PoE model for space-constrained deployments
  • It simplifies IT operations with next-gen Layer 2 switch series that provides entry-level, reliable, and convenient wired access connectivity
  • The CX6100 provides flexibility to manage and simplify configurations with HPE Aruba Networking Central, HPE Networking Switch Multi-Edit Software, easy to use Web GUI, or industry-standard CLI

Features

The HPE Networking CX6100 Switch Series provides flexibility to manage and simplify configurations with HPE Aruba Networking Central, HPE Networking Switch Multi-Edit Software, easy-to-use web GUI, or industry-standard CLI.

The HPE Networking CX6100 Switch Series offers gigabit connectivity with high-speed uplinks and optional PoE to provide entry-level, reliable, and convenient wired access connectivity for enterprise branch office and SMB networks.

The four built-in wire speed 1/10GbE uplinks mitigate bottlenecks at the access layer where users and devices connect.

AI-native performance and power

It has fully-managed enterprise-class switches deliver Layer 2 capabilities with support for static routing, access control lists (ACLs), robust quality of service (QoS), traffic prioritization, sFlow®, and IPv6.

Entry-level Layer 2 access switches

The switch series delivers a simple, consistent operator experience with the HPE Networking CX Switch Operating System (OS-CX) used across HPE Networking CX switching platforms.

The CX6100 series provides right-size deployment with choice of 12, 24, and 48-port 1U models with convenient built-in 1/10GbE uplinks and up to 740W of Class 4 PoE.

It simplifies ownership with no switch software licensing or subscriptions required.

The switch series offers unified management across wired, wireless, and WAN using HPE Aruba Networking Central.

It reduces manual IT operation tasks around initial deployment or on-going configuration changes to accommodate adds, moves, and changes with colorless ports using local user roles and local MAC authentication (LMA).

HPE Networking Switch Multi-Edit Software introduces automation that allows for rapid network-wide changes and verifies policy conformance post network updates.

It has up to 740W IEEE 802.3at Class 4 PoE with up to 30W per port supports newer Wi-Fi 7 and PoE devices.

The HPE Networking CX6100 Switch Series is designed with a dedicated ASIC that delivers very low latency, increased packet buffering, and adaptive power consumption needed for AI, Wi-Fi 7, and Internet of Things (IoT) requirements.

Simplified configuration and management

The CX6100 series is ready for software-defined networking with REST APIs for fine-grained programmability of network tasks.

It has the flexibility to mix 24 and 48-port modular and fixed CX6100 models.

It has a simplified configuration and management as the switches act as a single chassis when stacked.

It support for up to six switches (or members) in a stack through chain or ring topology.

It offers the flexibility to create stacks that span longer distances such as hundreds of meters across campuses to kilometers between sites.

It offers virtual switching framework (VSF) stacking – Scale and simplicity

Compatible products

Documents
