Lindy 150m Cat.6 HDMI 4K60, IR & RS-232 HDBaseT Extender
3.888,99 lei
Lindy 150m Cat.6 HDMI 4K60, IR & RS-232 HDBaseT Extender
(0)
Stoc epuizat
Vândut de RITC.ro
Cod produs: LY-38217
Livrare și beneficii
Compară cu produse similare
Lindy 150m Cat.6 HDMI 4K60, IR & RS-232 HDBaseT Extender
Extender HDMI & IR Lindy 70m C6 HDBaseT with PoC
887,99 lei 1.141,99 lei
HDMI Extender Lindy, 50m, Cat 6, HDMI 4K60, interfata HDMI
691,99 lei 889,99 lei
Lindy 50m Cat.6 HDMI & IR Extender with Loop Out
357,99 lei 433,99 lei
Extender Lindy fibra optica, distanta maxima 300m, latime de banda
2.019,99 lei 2.452,98 lei
Vezi comparația completă
| Caracteristică | Lindy 150m Cat.6 HDMI 4K60, IR & RS-232 HDBaseT Extender | Extender HDMI & IR Lindy 70m C6 HDBaseT with PoC | HDMI Extender Lindy, 50m, Cat 6, HDMI 4K60, interfata HDMI | Lindy 50m Cat.6 HDMI & IR Extender with Loop Out | Extender Lindy fibra optica, distanta maxima 300m, latime de banda |
|---|---|---|---|---|---|
| Culoare produs | Black | — | — | Black | Black |
| Cables included | AC, IR | — | AC | — | USB |
| Certification | CE, UKCA, FCC, RoHS, REACH & California Proposition 65 | — | CE. FCC, REACH | CE, FCC, RoHS, REACH | — |
| Chipset | VS010-A0 | — | — | GSV1001 | — |
| Extended display identification data (EDID) | Yes | — | Yes | Yes | — |
| HDMI in | 1 | 1 | — | 1 | — |
| Input current | 1 A | — | — | 1 A | — |
| Manual | Yes | — | — | Yes | Yes |
| Operating relative humidity (H-H) | 20 - 90% | 20 - 90% | — | 20 - 90% | — |
| Operating temperature (T-T) | 0 - 40 °C | — | — | 0 - 40 °C | — |
| Operating voltage | 24 V | 24 V | — | 12 V | — |
| Package depth | 75 mm | — | 540 mm | 70 mm | — |
| Package height | 185 mm | — | 283 mm | 113 mm | — |
| Package weight | 970 g | — | 1.19 kg | 414 g | — |
| Package width | 245 mm | — | 565 mm | 200 mm | — |
| RJ-45 input ports | 1 | 1 | — | 1 | — |
| Storage temperature (T-T) | -20 - 60 °C | -20 - 60 °C | — | -20 - 60 °C | — |
| Supported graphics resolutions | — | — | — | 1920 x 1080 (HD 1080), 3840 x 2160 | 3840 x 2160, 1920 x 1080 (HD 1080) |
| Supported video modes | — | 1080p | — | — | 1080p, 2160p |
| Greutate | 760 g | — | 9.26 kg | 130 g | — |
| Distanță maximă transfer | 150 m | 70 m | — | 70 m | 300 m |
| Rezoluție maximă | 3840 x 2160 pixels | — | 3840 x 2160 pixels | 3840 x 2160 pixels | 3840 x 2160 pixels |
| Material | Metal | — | — | Metal | — |
| Tip conexiune | Wired | Wired | — | Wired | — |
| Adâncime | 65 mm | — | 433.7 mm | 6.9 mm | — |
| Lățime | 140 mm | — | 483 mm | 79.5 mm | — |
| Înălțime | 18 mm | — | 132.5 mm | 16.5 mm | — |
| Versiune HDMI | 2.0 | — | — | 1.4 | — |
| Garanție comercială | 24 | 24 | 24 | 24 | 24 |
| Producător | LINDY | LINDY | LINDY | LINDY | LINDY |
| Număr porturi RJ-45 | 2 | 2 | 1 | 1 | N/A |
| Număr porturi USB | 1 | None | 1 | 1 | None |
| Tipuri cabluri suportate | Cat6 | Cat5e, Cat6, Cat7 | — | Cat6 | — |
| Versiune HDCP | 2.2 | — | 2.2 | 1.4 | — |
| Distanță maximă | 150 m | 70 m | 50 m | 70 m | 300 m |
| HDCP | Yes | — | — | Yes | — |
| Interfață HDMI | Da | Da | Da | Da | Da |
| Lățime de bandă | 18 Gbit/s | 10.2 Gbit/s | 18 Gbit/s | 10.2 Gbit/s | 10.2 Gbit/s |
| Lățime de bandă suportată | 18 Gbit/s | 10.2 Gbit/s | 18 Gbit/s | 10.2 Gbit/s | 5GBPS |
| Rezoluție maximă | 3840 x 2160 pixeli | 1920 x 1200 pixeli | 3840 x 2160 pixeli | 3840 x 2160 pixeli | 3840 x 2160 pixeli |
Analiză inteligentă a produsului
Descriere oficială
Lindy 150m Cat.6 HDMI 4K60, IR & RS-232 HDBaseT Extender Description Distributes HDMI resolutions up to 150m over Cat.6 network cable via HDBaseT & Long Reach technology Supports HDMI 18G resolutions up to 4K 3840×2160@60Hz 4:4:4, with additional support for HDR RS-232, CEC pass-through and bi-directional IR for simple control Supports PoC (Power over cable), requiring a power supply connection from only one side of the installation Technical details Specifications AV Interface: HDMI Interface Standard: HDMI 2.0 Supported Bandwidth: 18 Gbps Maximum Distance: 70m (229.66ft) – 3840×2160@60Hz 4:4:4 8bit 100m (328.08ft) – 3840×2160@30Hz 4:4:4 8bit 150m (492.12ft) – 1280×720@60Hz Maximum Resolution: 3840×2160@60Hz 4:4:4 8bit HDCP Support: 2.2 EDID Pass Through: Pass-through Supported Audio: HDMI Audio Pass-through Separate Audio Ports: – IR Support: 20KHz – 60KHz CEC Support: Pass-through Serial Interface: RS-232 (Bi-directional) Transmission Protocol: HDBaseT Transmission Medium: 1 x Cat.6 Laser Class (only for Fibre): – Wavelength (only for Fibre): – Chipset: VS010-A0 Special Features: HDMI Loop Out Port PoC (Power over Cat.6) Connectors Transmitter Input: HDMI Type A (Female), IR (Female) Transmitter Output: HDMI Type A (Female), RJ-45 (Female), IR (Female) Receiver Input: RJ-45 (Female) Receiver Output: HDMI Type A (Female), 3.5mm (Female) Bi-directional Ports: RS-232 (Female) Power: 5.5/2.1mm Physical Properties Dimensions (approx.) WxDxH: 140x65x18mm (5.51×2.56×0.71in) Housing Material: Metal Net Weight: 0.76kg (1.68lb) Operating Temperature: 0°C – 40°C (32°F – 104°F) Storage Temperature: -20°C – 60°C (-4°F – 140°F) Humidity: 20 – 90% RH (non-condensing) Power Requirements: 24VDC 1A Colour: Black Miscellaneous Packaging Type: Carton Box Packaging Dimensions: 245x75x185mm (9.65×2.95×7.28in) Gross Weight: 0.97kg (2.17lb) Warranty (Years): 2 Certificated: CE, UKCA, FCC, RoHS, REACH & California Proposition 65 Package Contents HDBaseT HDMI Extender, Transmitter HDBaseT HDMI Extender, Receiver IR Emitter Cable, 1.5m IR Receiver Cable, 1.5m 4 x Mounting Ears 2 x 3-Pin Terminal Block Multi-country Power Supply (UK, EU, US & AUS) Lindy Manual Purchasing Information No.: 38217 EAN: 4002888382175 https://www.lindy-international.com/150m-Cat-6-HDMI-4K60-IR-RS-232- HDBaseT-Extender-.htm?websale8=ld0101.ld021102&pi=38217 &ci=10
Specificații tehnice 46 caracteristici ⌄
- Culoare produs
- Black
- Intrare alimentare DC
- Yes
- Cables included
- AC, IR
- CEC pass-through
- Yes
- Certification
- CE, UKCA, FCC, RoHS, REACH & California Proposition 65
- Chipset
- VS010-A0
- Colour depth
- 4 bit
- Extended display identification data (EDID)
- Yes
- HDMI in
- 1
- Input current
- 1 A
- IR emitter included
- Yes
- LED indicators
- Yes
- Manual
- Yes
- Operating relative humidity (H-H)
- 20 - 90%
- Operating temperature (T-T)
- 0 - 40 °C
- Operating voltage
- 24 V
- Package depth
- 75 mm
- Package height
- 185 mm
- Package weight
- 970 g
- Package width
- 245 mm
- RJ-45 input ports
- 1
- RS-232 input ports
- 1
- Storage temperature (T-T)
- -20 - 60 °C
- Greutate
- 760 g
- Distanță maximă transfer
- 150 m
- Rezoluție maximă
- 3840 x 2160 pixels
- Material
- Metal
- Tip conexiune
- Wired
- Tip sursă alimentare
- DC
- Adâncime
- 65 mm
- Lățime
- 140 mm
- Înălțime
- 18 mm
- Versiune HDMI
- 2.0
- Garanție comercială
- 24
- Producător
- LINDY
- Număr porturi RJ-45
- 2
- Număr porturi USB
- 1
- Tipuri cabluri suportate
- Cat6
- Versiune HDCP
- 2.2
- Tip ambalare
- Box
- Distanță maximă
- 150 m
- HDCP
- Yes
- Interfață HDMI
- Da
- Lățime de bandă
- 18 Gbit/s
- Lățime de bandă suportată
- 18 Gbit/s
- Rezoluție maximă
- 3840 x 2160 pixeli
