Compară cu produse similare

Vezi comparația completă
Caracteristică Switch TP-Link TL-SF1016D, 16 port, 10/100 Mbps Switch TP-Link TL-SF1008D, 8 port, 10/100 Mbps Switch TP-Link TL-SF1016, 16 port, 10/100 Mbps "JetStream™ 8-Port 10GE SFP+ L2+ Managed Switch PORT: 8× 10G Omada 24-Port Gigabit Stackable Lite L3 Managed Switch with 4
Alte caracteristici
10G support No No No Yes Yes
Access Control List (ACL) Yes Yes
AC input frequency 50 - 60 Hz 50 - 60 Hz 50 - 60 Hz
ARP inspection Yes Yes
Auto-negotiation Yes Yes Yes
Auto MDI/MDI-X Yes Yes Yes
Basic switching RJ-45 Ethernet ports type Fast Ethernet (10/100) Fast Ethernet (10/100) Fast Ethernet (10/100) No 24
Broadcast storm control Yes Yes
Cables included AC AC AC
Cloud-managed Yes Yes
Compliance certificates CE, Federal Communications Commission (FCC), RoHS CE, Federal Communications Commission (FCC), RoHS CE, Federal Communications Commission (FCC), RoHS CE, Federal Communications Commission (FCC), RoHS
Console port RJ-45/micro-USB RJ-45
Copper ethernet cabling technology 100BASE-TX, 10BASE-T 10BASE-T, 100BASE-TX 10BASE-T, 100BASE-TX
DC input voltage 9 V 5 V
Depth 180 mm 7.9 mm 180 mm 180 mm 180 mm
DHCP features DHCP relay, DHCP server, DHCP snooping, DHCPv6 client, DHCPv6 snooping DHCP relay, DHCP server
Ethernet LAN data rates 10,100 Mbit/s 10,100 Mbit/s
Fanless Yes Yes Yes Yes
Fast Ethernet (copper) ports quantity 16 8 16
Flow control support Yes Yes Yes Yes
Forwarding rate 2.38 Mpps 119.04 Mpps 95.23 Mpps
Full duplex Yes Yes
Half duplex Yes Yes
Harmonized System (HS) code 85176990 85176990 85176990
Heat dissipation 11.01 BTU/h 6.99 BTU/h 7.03 BTU/h 52.75 BTU/h 66.87 BTU/h
Height 44 mm 22.5 mm 44 mm 44 mm
IGMP snooping Yes Yes
Input current 0.6 A 0.6 A
IP-MAC-Port binding Yes Yes
Jumbo frames 9000 9000
Jumbo frames support Yes Yes
LAN port type FastEthernet FastEthernet FastEthernet 10Gigabit
LED indicators Yes Yes Yes Yes Yes
Link aggregation Yes Yes
MAC address filtering Yes Yes
MAC address table 8000 entries 1000 entries 8000 entries 32000 entries 16000 entries
Management nu nu nu Da
Montare in rack Nu Nu Nu Nu Da
Multicast support Yes Yes
Networking standards IEEE 802.3i, IEEE 802.3u, IEEE 802.3x IEEE 802.3u, IEEE 802.3x IEEE 802.3i, IEEE 802.3u, IEEE 802.3x IEEE 802.1D, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad, IEEE 802.3x IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt
Number of VLANs 4000 4000
Operating relative humidity (H-H) 10 - 90% 10 - 90% 10 - 90% 10 - 90% 10 - 90%
Operating temperature (T-T) 0 - 40 °C 0 - 40 °C 0 - 40 °C 0 - 45 °C -5 - 45 °C
Package depth 285 mm 139 mm 528 mm
Package height 68 mm 85 mm
Package type Box Box Box Box
Package weight 590 g 240 g 2.28 kg
Package width 223 mm 100 mm 250 mm
Packet buffer memory 2 MB 2 MB 2 MB 16 MB 12 MB
PoE Nu Nu Nu Nu
Port mirroring Yes Yes
Porturi RJ 45 11-18 5-10 11-18 1-4 24-28
Porturi SFP N/A N/A N/A 5-8 3-4
Power connector DC-in jack DC-in jack DC-in jack DC-in jack
Power consumption (max) 3.23 W 2.2 W 2.23 W 15.46 W 19.6 W
Power over Ethernet (PoE) No No No No No
Power source DC DC AC AC AC
Power supply included Yes No Yes Yes Yes
Quality of Service (QoS) support Yes Yes
Quick start guide Yes Yes
Rack mounting Yes No Yes Yes Yes
Rack mount kit Yes Yes Yes
Security algorithms HTTPS, SSH, SSH-2, SSL/TLS SNMP, SNMPv2, SNMPv3
SFP module slots quantity 8 4
SSH/SSL support Yes Yes
Stackable No No No Yes
Static port security Yes Yes
Storage relative humidity (H-H) 5 - 90% 5 - 95% 5 - 90% 5 - 90% 5 - 90%
Storage temperature (T-T) -40 - 70 °C -40 - 70 °C -40 - 70 °C -40 - 70 °C -40 - 70 °C
Store-and-forward Yes Yes Yes Yes
Sustainability compliance Yes Yes Yes
Switching capacity 32 Gbit/s 16 Gbit/s 32 Gbit/s 160 Gbit/s 128 Gbit/s
Switch layer L2+/L3 L3
Switch type Unmanaged Unmanaged Unmanaged Managed Managed
Virtual LAN features Private VLAN, Protocol-based VLAN, Voice VLAN MAC address-based VLAN, Private VLAN, Protocol-based VLAN, Voice VLAN
Viteza transfer Fast Ethernet Fast Ethernet Fast Ethernet 10G+ Gigabit
VLAN support Yes Yes
Web-based management Yes Yes
Width 294 mm 134.5 mm 440 mm 440 mm
Laptopuri - Construcție
Culoare Black White Black
Laptopuri - Generale
Garanție comercială 36 36 36 60 24
Producător TP-LINK TP-LINK TP-LINK TP-LINK TP-LINK

Analiză inteligentă a produsului

În curând vei putea afla mai multe informații despre produs, generate cu inteligență artificială.

Descriere oficială

General
Numar porturi
16x RJ-45
Porturi
16x RJ45
Viteza de transfer
10/100 Mbps
Compatibilitate
802.3
802.3u
802.3x
Dimensiuni
200 x 142 x 40 mm
Functii LED
Da
Adrese MAC
1000
Metoda forwarding
Store and forward
Altele
MAC Address Auto-Learning and Auto-aging
Wire-speed Performance
Backbound Bandwidth: 3.2Gbps
Specificații tehnice 59 caracteristici
10G support
No
AC input frequency
50 - 60 Hz
Auto-negotiation
Yes
Auto MDI/MDI-X
Yes
Basic switching RJ-45 Ethernet ports type
Fast Ethernet (10/100)
Compliance certificates
CE, Federal Communications Commission (FCC), RoHS
Copper ethernet cabling technology
100BASE-TX, 10BASE-T
DC input voltage
9 V
Depth
180 mm
Ethernet LAN data rates
10,100 Mbit/s
Fanless
Yes
Fast Ethernet (copper) ports quantity
16
Flow control support
Yes
Full duplex
Yes
Half duplex
Yes
Harmonized System (HS) code
85176990
Heat dissipation
11.01 BTU/h
Height
44 mm
Input current
0.6 A
LAN port type
FastEthernet
LED indicators
Yes
MAC address auto-learning supported
Yes
MAC address table
8000 entries
Management
nu
Minimum system requirements
Microsoft Windows 98SE, NT, 2000, XP, Vista, Windows 7, MAC OS, NetWare, UNIX, Linux
Montare in rack
Nu
Networking standards
IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
Operating relative humidity (H-H)
10 - 90%
Operating temperature (T-T)
0 - 40 °C
Package depth
285 mm
Package height
68 mm
Package type
Box
Package weight
590 g
Package width
223 mm
Packet buffer memory
2 MB
PoE
Nu
Porturi RJ 45
11-18
Porturi SFP
N/A
Power connector
DC-in jack
Power consumption (max)
3.23 W
Power consumption (typical)
2.23 W
Power over Ethernet (PoE)
No
Power source
DC
Power supply included
Yes
Rack mounting
Yes
Stackable
No
Storage relative humidity (H-H)
5 - 90%
Storage temperature (T-T)
-40 - 70 °C
Store-and-forward
Yes
Sustainability compliance
Yes
Switching capacity
32 Gbit/s
Switch type
Unmanaged
Throughput
23.8 Mpps
Viteza transfer
Fast Ethernet
Wall mountable
Yes
Width
294 mm
Culoare
Black
Garanție comercială
36
Producător
TP-LINK
