CUDY 8-Port Gigabit Desktop Switch, 8 10/100/1000M RJ45 Ports, IGMP

Switchuri

CUDY 8-Port Gigabit Desktop Switch, 8 10/100/1000M RJ45 Ports, IGMP

(0) Stoc epuizat
Vândut de RITC.ro Cod produs: GS108D

Livrare și beneficii

Livrare rapidă 24–48 ore prin curier Livrare rapidă Retur gratuit în 30 de zile Retur 30 de Garanție inclusă 24 luni garanție oficială Garanție 24 luni

Compară cu produse similare

Vezi comparația completă
Caracteristică CUDY 8-Port Gigabit Desktop Switch, 8 10/100/1000M RJ45 Ports, IGMP Extralink KRATOS PoE Switch 7x Gigabit PoE 1x Switch TP-Link TL-SF1008D, 8 port, 10/100 Mbps Switch TP-Link TL-SF1016, 16 port, 10/100 Mbps Switch ALLIED TELESIS GS950, 48 port, 10/100/1000 Mbps
Alte caracteristici
10G support — No No No No
AC input frequency — 50 - 60 Hz 50 - 60 Hz 50 - 60 Hz 50 - 60 Hz
Auto-negotiation Yes Yes Yes Yes —
Auto MDI/MDI-X Yes — Yes Yes Yes
Basic switching RJ-45 Ethernet ports type 8 8 Fast Ethernet (10/100) Fast Ethernet (10/100) 48
Cables included DC — — AC —
Cable types supported Cat3, Cat4, Cat5, Cat5e, Cat6 Cat5, Cat5e, Cat6 — Cat3, Cat4, Cat5, Cat5e —
Certification — CE, FCC — — UL 1950, FCC/EN55022, VCCI, C-Tick, EN60950, EN55024, CE, CSA, CUL
Compliance certificates — — CE, Federal Communications Commission (FCC), RoHS CE, Federal Communications Commission (FCC), RoHS —
Copper ethernet cabling technology 10BASE-T, 100BASE-TX, 1000BASE-T — 10BASE-T, 100BASE-TX 10BASE-T, 100BASE-TX 1000BASE-T, 100BASE-TX
DC input voltage 5 V — 5 V — —
Depth 72.7 mm 8.2 mm 7.9 mm 180 mm 322 mm
Ethernet LAN data rates 10,100,1000 Mbit/s — — 10,100 Mbit/s —
Fanless — — Yes Yes —
Fast Ethernet (copper) ports quantity — — 8 16 —
Flow control support Yes — Yes Yes Yes
Form factor — 1U — 1U 1U
Full duplex Yes — Yes — —
Garantie 24 60 36 36 24
Half duplex Yes — Yes — —
Harmonized System (HS) code — — 85176990 85176990 85176990
Heat dissipation — — 6.99 BTU/h 7.03 BTU/h —
Height 26.9 mm 27 mm 22.5 mm 44 mm 43.5 mm
Housing material — Metal — Metal —
Input current 1 A 2.5 A 0.6 A — —
LAN ports 8 — — — 48
LAN port type Gigabit Gigabit FastEthernet FastEthernet Gigabit
Layer Layer-2 — — — Layer-2
LED indicators Activity, Link, Power Yes Yes Yes Yes
MAC address table — 4096 entries 1000 entries 8000 entries 8000 entries
Management nu nu nu nu Da
Montare in rack Nu Nu Nu Nu Da
Networking standards IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x IEEE 802.3af IEEE 802.3u, IEEE 802.3x IEEE 802.3i, IEEE 802.3u, IEEE 802.3x —
Operating relative humidity (H-H) 10 - 90% 10 - 80% 10 - 90% 10 - 90% 5 - 90%
Operating temperature (T-T) 0 - 40 °C 0 - 40 °C 0 - 40 °C 0 - 40 °C 0 - 40 °C
Package depth — — 139 mm 528 mm —
Package type Box — Box Box —
Package weight — — 240 g 2.28 kg —
Package width — — 100 mm 250 mm —
Packet buffer memory — — 2 MB 2 MB 6 MB
PoE Nu Da Nu Nu Nu
Port mirroring — No — — Yes
Porturi RJ 45 5-10 5-10 5-10 11-18 28+
Porturi SFP N/A N/A N/A N/A 1-2
Power connector — DC-in jack DC-in jack DC-in jack DC-in jack
Power consumption (max) 2.3 W — 2.2 W 2.23 W —
Power over Ethernet (PoE) No Yes No No No
Power source DC AC DC AC —
Power supply included Yes Yes No Yes —
Product colour Black Black White Black Grey
Quality of Service (QoS) support — No — — Yes
Rackable No — — — Yes
Rack mounting No No No Yes Yes
Redundant PSU No — — — No
Stackable No No No No No
Storage relative humidity (H-H) 5 - 95% 5 - 90% 5 - 95% 5 - 90% 5 - 95%
Storage temperature (T-T) -40 - 70 °C -40 - 70 °C -40 - 70 °C -40 - 70 °C -25 - 70 °C
Store-and-forward Yes — Yes Yes —
Sustainability compliance — — Yes Yes —
Switching capacity 16 Gbit/s 16 Gbit/s 16 Gbit/s 32 Gbit/s —
Switch layer — L2 — — L2
Switch type — Unmanaged Unmanaged Unmanaged Managed
Viteza transfer Gigabit Gigabit Fast Ethernet Fast Ethernet Gigabit
Web-based management — No — — Yes
Weight 215 g 500 g — — 4.05 kg
Width 143 mm 192 mm 134.5 mm 440 mm 444 mm
Producator CUDY EXTRALINK TP-LINK TP-LINK ALLIED TELESIS

Analiză inteligentă a produsului

În curând vei putea afla mai multe informații despre produs, generate cu inteligență artificială.

Descriere oficială

CUDY 8-Port Gigabit Desktop Switch, 8 10/100/1000M RJ45 Ports, IGMP Snooping, Loop Detection/Prevention, 802.1p/DSCP QoS, Desktop Plastic Case, Power Saving, Plug & Play, Wall-Mount

Specificații tehnice 53 caracteristici
Auto-negotiation
Yes
Auto MDI/MDI-X
Yes
Bandwidth
1.6 Gbit/s
Basic switching RJ-45 Ethernet ports type
8
Cables included
DC
Cable types supported
Cat3, Cat4, Cat5, Cat5e, Cat6
Copper ethernet cabling technology
10BASE-T, 100BASE-TX, 1000BASE-T
DC input voltage
5 V
Depth
72.7 mm
Ethernet LAN data rates
10,100,1000 Mbit/s
Flow control support
Yes
Full duplex
Yes
Garantie
24
Half duplex
Yes
Height
26.9 mm
Input current
1 A
LAN ports
8
LAN port type
Gigabit
Layer
Layer-2
LED indicators
Activity, Link, Power
MAC address auto-aging supported
Yes
MAC address auto-learning supported
Yes
Management
nu
Manual
Yes
Montare in rack
Nu
Networking standards
IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Operating relative humidity (H-H)
10 - 90%
Operating temperature (T-T)
0 - 40 °C
Package type
Box
Packet forwarding rate (1 Gbps)
1488000 pps
Packet forwarding rate (10 Mbps)
14880 pps
Packet forwarding rate (100 Mbps)
148800 pps
Plug and Play
Yes
PoE
Nu
Porturi RJ 45
5-10
Porturi SFP
N/A
Power consumption (max)
2.3 W
Power over Ethernet (PoE)
No
Power source
DC
Power supply included
Yes
Product colour
Black
Rackable
No
Rack mounting
No
Redundant PSU
No
Stackable
No
Storage relative humidity (H-H)
5 - 95%
Storage temperature (T-T)
-40 - 70 °C
Store-and-forward
Yes
Switching capacity
16 Gbit/s
Viteza transfer
Gigabit
Weight
215 g
Width
143 mm
Producator
CUDY
