MERCUSYS DESKTOP SWITCH 10PORT MS110P POE, Interfata: 10× 10/100

Switchuri

MERCUSYS DESKTOP SWITCH 10PORT MS110P POE, Interfata: 10× 10/100

(0) Stoc epuizat
Vândut de RITC.ro Cod produs: MS110P

Livrare și beneficii

Livrare rapidă 24–48 ore prin curier Livrare rapidă Retur gratuit în 30 de zile Retur 30 de Garanție inclusă 24 luni garanție oficială Garanție 24 luni

Compară cu produse similare

Vezi comparația completă
Caracteristică MERCUSYS DESKTOP SWITCH 10PORT MS110P POE, Interfata: 10× 10/100 Switch TP-Link TL-SG1024D, 24 port, 10/100/1000 Mbps "JetStream™ 48-Port Gigabit and 4-Port 10GE SFP+ L2+ Managed Switch "JetStream™ 24-Port 2.5GBASE-T and 4-Port 10GE SFP+ L2+ Managed Switch Extralink KRATOS PoE Switch 7x Gigabit PoE 1x
Alte caracteristici
10G support No No Yes Yes No
Access Control List (ACL) — — Yes Yes —
AC input frequency 50 Hz 50 - 60 Hz — — 50 - 60 Hz
ARP inspection — — Yes Yes —
Authentication — — Auto VLAN, Guest VLAN Guest VLAN, MAC-based authentication, Port-based authentication —
Auto-negotiation Yes Yes — — Yes
Auto MDI/MDI-X Yes Yes — — —
Basic switching RJ-45 Ethernet ports type 10 24 48 24 8
BPDU filtering/protection — — Yes Yes —
Broadcast storm control — — Yes Yes —
Cables included AC AC AC AC —
Cable types supported — Cat3, Cat4, Cat5, Cat5e — — Cat5, Cat5e, Cat6
Cloud-managed — — Yes Yes No
Configuring Location Settings (CLI) — — Yes Yes No
Console port — — RJ-45/micro-USB RJ-45/micro-USB —
DHCP features — — DHCP client, DHCP relay, DHCP server DHCP client, DHCP relay, DHCP server, DHCP snooping, DHCPv6 client, DHCPv6 snooping —
Flow control support Yes Yes Yes Yes —
Forwarding rate — 35.7 Mpps 130.9 Mpps 148.8 Mpps —
Full duplex Yes Yes — Yes —
Head-of-line (HOL) blocking — — Yes Yes —
Heat dissipation 263.568 BTU/h 44.63 BTU/h 2169.2 BTU/h 2153.45 BTU/h —
IGMP snooping — — Yes Yes —
Input current 1.31 A — — — 2.5 A
IP-MAC-Port binding — — Yes Yes —
Jumbo frames — 10000 9000 9000 —
Jumbo frames support — Yes Yes Yes —
LAN ports 8 24 48 24 —
LAN port type FastEthernet Gigabit Gigabit Gigabit Gigabit
Layer Unmanaged Unmanaged Layer-2 Layer-2 —
LED indicators — Yes Yes Yes Yes
Link aggregation — — Yes Yes —
MAC address table 2000 entries 8000 entries 16000 entries 32000 entries 4096 entries
Management nu nu Da Da nu
Montare in rack Nu Nu Da Da Nu
Multicast support — — Yes Yes —
Networking standards IEEE 802.3af, IEEE 802.3at, IEEE 802.3x IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x — — IEEE 802.3af
Number of fans — — 3 fan(s) 3 fan(s) —
Operating relative humidity (H-H) 10 - 90% 10 - 90% 10 - 90% 10 - 90% 10 - 80%
Operating temperature (T-T) 0 - 40 °C 0 - 40 °C 0 - 40 °C 0 - 40 °C 0 - 40 °C
Packet buffer memory — — 12 MB 16 MB —
PoE Da Nu Da Da Da
Port mirroring — — Yes Yes No
Porturi RJ 45 5-10 24-28 28+ 24-28 5-10
Porturi SFP N/A N/A 1-2 1-2 N/A
Power connector — DC-in jack AC-in jack — DC-in jack
Power consumption (max) 77.52 W 13.08 W 635.7 W 629.1 W —
Power over Ethernet (PoE) Yes No Yes Yes Yes
Power over Ethernet (PoE) power per port 65 W — 30 W — 30 W
Power over Ethernet plus (PoE+) ports quantity 2 — 48 16 —
Power source AC AC AC AC/PoE AC
Power supply included Yes Yes Yes Yes Yes
Quality of Service (QoS) support — Yes Yes Yes No
Quick start guide No — Yes Yes —
Rackable No No Yes Yes —
Rack mounting No Yes Yes Yes No
Rack mount kit — Yes — Yes —
Rate limiting — — Yes Yes —
Redundant fans support — — — Yes No
Redundant PSU No Yes No Yes —
Reset button — — Yes — Yes
SFP module slots quantity — — 4 4 —
Spanning tree protocol — — Yes Yes —
SSH/SSL support — — Yes Yes —
Stackable No Yes No No No
Static port security — — Yes Yes —
Storage relative humidity (H-H) 5 - 95% 5 - 90% 5 - 90% 5 - 90% 5 - 90%
Storage temperature (T-T) -40 - 70 °C -40 - 70 °C -40 - 70 °C -40 - 70 °C -40 - 70 °C
Store-and-forward — Yes Yes Yes —
Switching capacity — 48 Gbit/s 176 Gbit/s 200 Gbit/s 16 Gbit/s
Switch type Managed Unmanaged Managed Managed Unmanaged
System event log — — Yes Yes No
Total Power over Ethernet (PoE) budget — — 500 W 500 W 60 W
Viteza transfer Fast Ethernet Gigabit 10G+ 2.5G Gigabit
VLAN support — — Yes Yes —
Web-based management Yes — Yes Yes No
Laptopuri - Caracteristici fizice 25.09
Adâncime 98 mm 180 mm 330 mm 330 mm 8.2 mm
Lățime 171 mm 294 mm — — 192 mm
Înălțime 27 mm 44 mm — — 27 mm
Laptopuri - Conectivitate și porturi 25.09
Viteză rețea LAN 10,100 Mbit/s — — 10,100,1000,2500,10000 Mbit/s —
Laptopuri - Construcție
Culoare Black Grey — — Black
Laptopuri - Generale
Garanție comercială 24 60 60 24 60
Producător MERCUSYS TP-LINK TP-LINK TP-LINK EXTRALINK
Laptopuri - Tip laptop
Construcție laptop — — 1U 1U 1U

Analiză inteligentă a produsului

În curând vei putea afla mai multe informații despre produs, generate cu inteligență artificială.

Descriere oficială

MERCUSYS DESKTOP SWITCH 10PORT MS110P POE, Interfata: 10× 10/100 Mbps, Standarde si protocoale: IEEE 802.3x Flow Control, Dimensiuni: 171*98* 27 mm, Porturi POE: 1-8, Buget POE: 65W.

Specificații tehnice 51 caracteristici
10G support
No
AC input frequency
50 Hz
AC input voltage
220 V
Auto-negotiation
Yes
Auto MDI/MDI-X
Yes
Basic switching RJ-45 Ethernet ports type
10
Cables included
AC
DC input voltage
53.5 V
Flow control support
Yes
Full duplex
Yes
Heat dissipation
263.568 BTU/h
Input current
1.31 A
LAN ports
8
LAN port type
FastEthernet
Layer
Unmanaged
MAC address table
2000 entries
Management
nu
Montare in rack
Nu
Networking standards
IEEE 802.3af, IEEE 802.3at, IEEE 802.3x
Operating relative humidity (H-H)
10 - 90%
Operating temperature (T-T)
0 - 40 °C
PoE
Da
Policy-based routing
Yes
Porturi RJ 45
5-10
Porturi SFP
N/A
Power consumption (max)
77.52 W
Power consumption (typical)
2.96 W
Power over Ethernet (PoE)
Yes
Power over Ethernet (PoE) ports quantity
8
Power over Ethernet (PoE) power per port
65 W
Power over Ethernet plus (PoE+) ports quantity
2
Power source
AC
Power supply included
Yes
Quick start guide
No
Rackable
No
Rack mounting
No
Redundant PSU
No
Stackable
No
Storage relative humidity (H-H)
5 - 95%
Storage temperature (T-T)
-40 - 70 °C
Switch type
Managed
Viteza transfer
Fast Ethernet
Wall mountable
Yes
Web-based management
Yes
Adâncime
98 mm
Lățime
171 mm
Înălțime
27 mm
Viteză rețea LAN
10,100 Mbit/s
Culoare
Black
Garanție comercială
24
Producător
MERCUSYS
