Switch D-Link DGS-1100-08V2, 8 port, 10/100/1000 Mbps

Switchuri

Switch D-Link DGS-1100-08V2, 8 port, 10/100/1000 Mbps

(0) În stoc
Vândut de RITC.ro Cod produs: DGS-1100-08V2

Livrare și beneficii

Livrare rapidă 24–48 ore prin curier Livrare rapidă Retur gratuit în 30 de zile Retur 30 de Garanție inclusă 24 luni garanție oficială Garanție 24 luni

Compară cu produse similare

Vezi comparația completă
Caracteristică Switch D-Link DGS-1100-08V2, 8 port, 10/100/1000 Mbps Extralink KRATOS PoE Switch 7x Gigabit PoE 1x Switch TP-Link TL-SF1008D, 8 port, 10/100 Mbps "JetStream™ 8-Port 10GE SFP+ L2+ Managed Switch PORT: 8× 10G Switch ALLIED TELESIS GS950, 48 port, 10/100/1000 Mbps
Alte caracteristici
10G support — No No Yes No
AC input frequency — 50 - 60 Hz 50 - 60 Hz — 50 - 60 Hz
Auto-negotiation — Yes Yes — —
Auto MDI/MDI-X Yes — Yes — Yes
Basic switching RJ-45 Ethernet ports type 8 8 Fast Ethernet (10/100) No 48
Broadcast storm control — — — Yes Yes
Certification — CE, FCC — — UL 1950, FCC/EN55022, VCCI, C-Tick, EN60950, EN55024, CE, CSA, CUL
Cloud-managed — No — Yes —
Configuring Location Settings (CLI) — No — Yes —
Console port — — — RJ-45/micro-USB RJ-45
Copper ethernet cabling technology 1000BASE-T — 10BASE-T, 100BASE-TX — 1000BASE-T, 100BASE-TX
DC input voltage 5 V — 5 V — —
Depth 28 mm 8.2 mm 7.9 mm 180 mm 322 mm
DHCP features — — — DHCP relay, DHCP server, DHCP snooping, DHCPv6 client, DHCPv6 snooping DHCP client
Fanless Yes — Yes — —
Flow control support — — Yes Yes Yes
Form factor — 1U — — 1U
Forwarding rate 11.9 Mpps — — 119.04 Mpps —
Garantie 60 60 36 60 24
Harmonized System (HS) code — — 85176990 — 85176990
Head-of-line (HOL) blocking — — — Yes Yes
Heat dissipation — — 6.99 BTU/h 52.75 BTU/h —
Height 82 mm 27 mm 22.5 mm — 43.5 mm
IGMP snooping — — — Yes Yes
Input current 1 A 2.5 A 0.6 A — —
Jumbo frames 9216 — — 9000 —
Jumbo frames support Yes — — Yes Yes
LAN port type Gigabit Gigabit FastEthernet 10Gigabit Gigabit
LED indicators — Yes Yes Yes Yes
Link aggregation — — — Yes Yes
MAC address filtering — — — Yes Yes
MAC address table 4000 entries 4096 entries 1000 entries 32000 entries 8000 entries
Management Da nu nu Da Da
Management protocols — — — SNMPv1/v2c/v3, SNTP IGMP, SNMP, FTP
MIB support — — — RFC2925, RFC2618, RFC2620, RFC2021, RFC2819, RFC2674, RFC1493, RFC1643, RFC2233, RFC1213 RFC 1213, RFC 1643, RFC 1493
Montare in rack Da Nu Nu Nu Da
Multicast support — — — Yes Yes
Networking standards — IEEE 802.3af IEEE 802.3u, IEEE 802.3x IEEE 802.1D, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad, IEEE 802.3x —
Operating relative humidity (H-H) 0 - 90% 10 - 80% 10 - 90% 10 - 90% 5 - 90%
Operating temperature (T-T) 0 - 40 °C 0 - 40 °C 0 - 40 °C 0 - 45 °C 0 - 40 °C
Package type — — Box Box —
Packet buffer memory 1.5 MB — 2 MB 16 MB 6 MB
PoE Nu Da Nu Nu Nu
Port mirroring — No — Yes Yes
Porturi RJ 45 5-10 5-10 5-10 1-4 28+
Porturi SFP N/A N/A N/A 5-8 1-2
Power connector — DC-in jack DC-in jack DC-in jack DC-in jack
Power consumption (max) 4.94 W — 2.2 W 15.46 W —
Power over Ethernet (PoE) No Yes No No No
Power source AC AC DC AC —
Power supply included — Yes No Yes —
Product colour Black Black White — Grey
Quality of Service (QoS) support Yes No — Yes Yes
Quick start guide — — Yes Yes —
Rack mounting No No No Yes Yes
Rate limiting — — — Yes Yes
Reset button Yes Yes — — —
Spanning tree protocol — — — Yes Yes
Stackable — No No — No
Static port security — — — Yes Yes
Storage relative humidity (H-H) 0 - 95% 5 - 90% 5 - 95% 5 - 90% 5 - 95%
Storage temperature (T-T) -40 - 70 °C -40 - 70 °C -40 - 70 °C -40 - 70 °C -25 - 70 °C
Switching capacity 16 Gbit/s 16 Gbit/s 16 Gbit/s 160 Gbit/s —
Switch layer L2 L2 — L2+/L3 L2
Switch type Managed Unmanaged Unmanaged Managed Managed
System event log — No — Yes —
Traffic classification — No — Yes —
Viteza transfer Gigabit Gigabit Fast Ethernet 10G+ Gigabit
VLAN support — — — Yes Yes
Web-based management Yes No — Yes Yes
Weight 340 g 500 g — — 4.05 kg
Width 145 mm 192 mm 134.5 mm — 444 mm
Producator D-LINK EXTRALINK TP-LINK TP-LINK ALLIED TELESIS

Analiză inteligentă a produsului

În curând vei putea afla mai multe informații despre produs, generate cu inteligență artificială.

Descriere oficială

Numar porturi
8x RJ-45
Porturi
8x RJ45
Viteza de transfer
10/100/1000 Mbps
Management
Da
Putere consumata
4.94 W
Alimentare
100 – 220 V
Dimensiuni
145 x 82 x 28 mm
Greutate
340g
Memorie Buffer
1.5 Mbits
Memorie
Flash: 2 MB
Adrese MAC
4K
Metoda forwarding
11.9 Mpps
Routing/Switch Fabric
16 Gbps
Specificații tehnice 41 caracteristici
Auto MDI/MDI-X
Yes
Basic switching RJ-45 Ethernet ports type
8
Copper ethernet cabling technology
1000BASE-T
DC input voltage
5 V
Depth
28 mm
Fanless
Yes
Forwarding rate
11.9 Mpps
Garantie
60
Height
82 mm
Input current
1 A
Jumbo frames
9216
Jumbo frames support
Yes
LAN port type
Gigabit
MAC address table
4000 entries
Management
Da
Montare in rack
Da
Number of fans
0 fan(s)
Operating altitude
0 - 2000 m
Operating relative humidity (H-H)
0 - 90%
Operating temperature (T-T)
0 - 40 °C
Packet buffer memory
1.5 MB
PoE
Nu
Porturi RJ 45
5-10
Porturi SFP
N/A
Power consumption (max)
4.94 W
Power over Ethernet (PoE)
No
Power source
AC
Product colour
Black
Quality of Service (QoS) support
Yes
Rack mounting
No
Reset button
Yes
Storage relative humidity (H-H)
0 - 95%
Storage temperature (T-T)
-40 - 70 °C
Switching capacity
16 Gbit/s
Switch layer
L2
Switch type
Managed
Viteza transfer
Gigabit
Web-based management
Yes
Weight
340 g
Width
145 mm
Producator
D-LINK
